基于Deepseek视觉语言模型识别与训练九宫格验证码

ops 2025/7/28 5:25:34

主题

验证码示例

适用验证码: 某验、某歌等厂商验证码
在这里插入图片描述

在这里插入图片描述

训练思路

爬虫采集验证码图片集
基于视觉模型识别九宫格中9张小图
切割九宫格的九张小图
基于视觉模型识别结果对每张小图进行分类标注，标注完成之后则得到了分类训练的数据集
基于数据集训练分类模型
训练完成之后，测试模型效果

技术栈

工具	–
语言	Python
视觉模型	deepseek-ai/deepseek-vl2
模型API平台	siliconflow (硅基流动)
分类模型	YOLOv8

训练步骤

爬虫采集图片集

使用模拟浏览器访问验证码页面，截图保存九宫格验证码
或者访问接口采集验证码图片

顶部附件提供了部分数据集供测试使用（仅20张九宫格图片）

基于Deepseek视觉模型识别图片内容

此处使用siliconflow api, TOKEN 为你的api秘钥，点击此处获取


TOKEN = '你的硅基流动api密钥'ALL_CLASS = ["积木","船","方向盘","骆驼","剪刀","兔子","猪","行李箱","火箭","打印机","碗","地球仪","秋千","冰箱","贝壳","拉链","铲子","长颈鹿","望远镜","烟斗","鼠标","订书机","眼镜","公鸡","气球","计算器","水壶","桌子","鸟","叉子","听诊器","摩托车","伞","牛","领带","电钻","乌龟","纽扣","熊猫","捕蚊拍","手电筒","螺丝刀","铁轨","轮胎","口红","插座","笔","钥匙","井盖","狗","牙刷","狮子","瓢虫","台灯","老虎","鳄鱼","蝴蝶","头盔","羽毛球","羊","企鹅","足球","梳子","老虎","帽子","交通信号灯","注射器","喷泉","鱼","手套","桥","袜子","鹿","键盘","钱包","袋鼠","书","椅子","公交车","猫","猴子","手表","台球","相机","救护车","轮椅","锅","过山车","音响","齿轮",

切割九宫格图片

def split_sudoku(image_path, gap=5):# 打开原始图片original_img = Image.open(image_path)width, height = original_img.size# 计算每个小图的尺寸tile_width = (width - 1 * gap) // 3tile_height = (height - 1 * gap) // 3# 分割并保存9张图片for row in range(3):for col in range(3):# 计算每个小图的左上和右下坐标left = col * (tile_width + gap)upper = row * (tile_height + gap)right = left + tile_widthlower = upper + tile_height# 裁剪图片tile = original_img.crop((left, upper, right, lower))yield tile

九宫格小图标注

if __name__ == '__main__':image_dir = 'images_origin'for index, image_name in enumerate(os.listdir(image_dir)):image_path = os.path.join(image_dir, image_name)# 视觉模型识别content = chat_with_vl(image_path)content = content.strip('```').strip('json')print('image_path', image_path, 'content', content)try:no_to_name = json.loads(content)except Exception as e:print('图片识别失败', content)continuefor i, tile in enumerate(split_sudoku(image_path)):no = i + 1tile_class = no_to_name.get(str(no))if tile_class is None:continueclass_dir = os.path.join('datasets', tile_class)if not os.path.exists(class_dir):os.makedirs(class_dir)# tile图片保存到class_dir文件夹，图片名格式为{image_name}_{no}.pngtile.save(os.path.join(class_dir, image_name.split('.')[0] + '_' + str(no) + '.png'))

拆分数据集为 test（测试数据集）和 train（训练数据集）

import os
import shutildef split_dataset(origin_dir, target_dir, train_ratio=0.8):# 确保目标目录存在if not os.path.exists(target_dir):os.makedirs(target_dir)# 创建train和test目录train_dir = os.path.join(target_dir, 'train')test_dir = os.path.join(target_dir, 'test')os.makedirs(train_dir, exist_ok=True)os.makedirs(test_dir, exist_ok=True)# 遍历origin_dir下的所有子文件夹for class_name in os.listdir(origin_dir):class_path = os.path.join(origin_dir, class_name)if os.path.isdir(class_path):# 创建train和test子文件夹train_class_dir = os.path.join(train_dir, class_name)test_class_dir = os.path.join(test_dir, class_name)os.makedirs(train_class_dir, exist_ok=True)os.makedirs(test_class_dir, exist_ok=True)# 获取所有图片文件images = [f for f in os.listdir(class_path) if f.endswith(('.png', '.jpg', '.jpeg', '.bmp', '.gif'))]# 计算分割点split_index = int(len(images) * train_ratio)# 分割图片到train和test文件夹for i, image in enumerate(images):src_image_path = os.path.join(class_path, image)if i < split_index:dst_image_path = os.path.join(train_class_dir, image)else:dst_image_path = os.path.join(test_class_dir, image)shutil.copy(src_image_path, dst_image_path)# 使用示例
origin_dir = 'datasets'
target_dir = 'datasets-split'
split_dataset(origin_dir, target_dir)

拆分好的数据集文件夹为 datasets-split

训练模型

from ultralytics import YOLOmodel = YOLO("models/yolov8n-cls.pt")model.train(data="datasets-split",epochs=500,imgsz=128,batch=16,device='cpu',name="suduku",patience=50,
)print('done')

测试模型效果

import osfrom ultralytics import YOLO# 测试模型效果
onnx_model = YOLO("runs/classify/suduku/weights/best.pt",task='classify')dirpath = '<test image>'for file in os.listdir(dirpath):file_path = os.path.join(dirpath, file)results = onnx_model.predict(source=file_path,imgsz=128,)# Process results listfor result in results:print(result.probs.top1)print(result.probs.top1conf)print(result.probs.top5)print(result.probs.top5conf)
