第25节：VR基础与WebXR API入门

第25节：VR基础与WebXR API入门

概述

虚拟现实（VR）正在重塑人机交互的边界，而WebXR让这一切在浏览器中成为可能。本节将深入探索WebXR技术体系，从设备集成到交互处理，从立体渲染到性能优化，为您提供构建沉浸式WebVR应用的完整解决方案。

WebXR生态系统建立在多层技术栈之上，其核心架构如下：

核心原理深度解析

WebXR技术架构

WebXR API提供了访问VR/AR设备的标准化接口，其核心组件包括：

立体渲染原理

VR渲染与传统3D渲染的关键差异：

1. 双眼视差渲染

   • 左眼和右眼分别渲染独立视角
   • 瞳距（IPD）调整和校准
   • 视口分割和投影矩阵计算

2. 性能优化要求

   • 目标帧率：72-90 FPS（PC VR）、72 FPS（Quest）
   • 渲染分辨率：每眼1.4-2.0倍原生分辨率（超采样）
   • 绘制调用优化：每帧<100 draw calls

完整代码实现

高级WebXR集成系统

<template><div ref="container" class="xr-container"><!-- 主渲染画布 --><canvas ref="rendererCanvas" class="xr-canvas"></canvas><!-- XR控制界面 --><div v-if="!isXRSessionActive" class="xr-controls"><div class="xr-control-panel"><h2>WebXR体验控制器</h2><div class="device-status"><div class="status-item"><span class="status-label">XR支持:</span><span class="status-value" :class="{'supported': xrSupport}">{{ xrSupport ? '可用' : '不可用' }}</span></div><div class="status-item" v-if="xrSupport"><span class="status-label">设备类型:</span><span class="status-value">{{ xrDeviceType || '未检测' }}</span></div></div><div class="session-buttons" v-if="xrSupport"><button @click="enterVR()" :disabled="!canEnterVR"class="xr-button vr-button">🕶️ 进入VR模式</button><button @click="enterAR()" :disabled="!canEnterAR"class="xr-button ar-button">📱 进入AR模式</button></div><div class="quality-settings" v-if="xrSupport"><h3>渲染质量设置</h3><div class="setting-group"><label>渲染比例: {{ renderScale }}x</label><input type="range" v-model="renderScale" min="0.5" max="1.5" step="0.1"></div><div class="setting-group"><label>抗锯齿: {{ msaaEnabled ? '开启' : '关闭' }}</label><input type="checkbox" v-model="msaaEnabled"></div></div></div></div><!-- XR会话状态指示 --><div v-if="isXRSessionActive" class="xr-session-info"><div class="session-stats"><span>FPS: {{ currentFPS }}</span><span>DrawCalls: {{ currentDrawCalls }}</span><span>控制器: {{ controllerCount }}</span></div><button @click="exitXR()" class="exit-button">🚪 退出XR</button></div><!-- 加载状态 --><div v-if="isLoading" class="loading-overlay"><div class="loading-content"><div class="spinner"></div><p>初始化XR环境...</p><p class="loading-details">{{ loadingStatus }}</p></div></div></div>
</template><script>
import { onMounted, onUnmounted, ref, reactive } from 'vue';
import * as THREE from 'three';
import { OrbitControls } from 'three/addons/controls/OrbitControls.js';
import { VRButton } from 'three/addons/webxr/VRButton.js';
import { XRControllerModelFactory } from 'three/addons/webxr/XRControllerModelFactory.js';export default {name: 'WebXRExperience',setup() {const container = ref(null);const rendererCanvas = ref(null);const isXRSessionActive = ref(false);const xrSupport = ref(false);const xrDeviceType = ref('');const canEnterVR = ref(false);const canEnterAR = ref(false);const isLoading = ref(false);const loadingStatus = ref('');const renderScale = ref(1.0);const msaaEnabled = ref(true);const currentFPS = ref(0);const currentDrawCalls = ref(0);const controllerCount = ref(0);let scene, camera, renderer, controls;let xrSession = null;let xrReferenceSpace = null;let xrButton = null;let controllers = [];let clock = new THREE.Clock();let frameCount = 0;let lastFpsUpdate = 0;// 初始化Three.js和WebXR环境const init = async () => {isLoading.value = true;loadingStatus.value = '初始化渲染器...';try {// 初始化Three.js核心组件initThreeJS();// 检测WebXR支持await checkXRSupport();// 创建场景内容createSceneContent();// 设置XR控制器setupXRControllers();// 启动渲染循环animate();} catch (error) {console.error('初始化失败:', error);} finally {isLoading.value = false;}};// 初始化Three.jsconst initThreeJS = () => {// 创建场景scene = new THREE.Scene();scene.background = new THREE.Color(0x080808);// 创建相机camera = new THREE.PerspectiveCamera(75,window.innerWidth / window.innerHeight,0.1,1000);camera.position.set(0, 1.6, 3); // 默认身高位置// 创建渲染器renderer = new THREE.WebGLRenderer({canvas: rendererCanvas.value,antialias: msaaEnabled.value,alpha: true});renderer.setSize(window.innerWidth, window.innerHeight);renderer.setPixelRatio(Math.min(window.devicePixelRatio, 2));renderer.xr.enabled = true;renderer.xr.setReferenceSpaceType('local-floor');// 添加VR按钮xrButton = VRButton.createButton(renderer);container.value.appendChild(xrButton);// 添加轨道控制器（非XR模式）controls = new OrbitControls(camera, renderer.domElement);controls.enableDamping = true;};// 检测WebXR支持const checkXRSupport = async () => {if (!navigator.xr) {xrSupport.value = false;throw new Error('WebXR API不可用');}try {// 检测VR支持canEnterVR.value = await navigator.xr.isSessionSupported('immersive-vr');// 检测AR支持canEnterAR.value = await navigator.xr.isSessionSupported('immersive-ar');xrSupport.value = canEnterVR.value || canEnterAR.value;if (canEnterVR.value) {xrDeviceType.value = 'VR设备';} else if (canEnterAR.value) {xrDeviceType.value = 'AR设备';}} catch (error) {console.error('XR支持检测失败:', error);xrSupport.value = false;}};// 创建场景内容const createSceneContent = () => {// 添加环境光const ambientLight = new THREE.AmbientLight(0x404040, 0.6);scene.add(ambientLight);// 添加方向光const directionalLight = new THREE.DirectionalLight(0xffffff, 0.8);directionalLight.position.set(5, 10, 5);directionalLight.castShadow = true;scene.add(directionalLight);// 创建地面const floorGeometry = new THREE.PlaneGeometry(20, 20);const floorMaterial = new THREE.MeshStandardMaterial({color: 0x888888,roughness: 0.8,metalness: 0.2});const floor = new THREE.Mesh(floorGeometry, floorMaterial);floor.rotation.x = -Math.PI / 2;floor.receiveShadow = true;floor.position.y = -0.1;scene.add(floor);// 创建交互物体createInteractiveObjects();// 创建环境边界指示createBoundaryIndicator();};// 创建交互物体const createInteractiveObjects = () => {// 创建可交互的立方体const cubeGeometry = new THREE.BoxGeometry(0.5, 0.5, 0.5);const cubeMaterial = new THREE.MeshStandardMaterial({color: 0xff0000,emissive: 0x440000,metalness: 0.7,roughness: 0.3});const cube = new THREE.Mesh(cubeGeometry, cubeMaterial);cube.position.set(0, 0.5, -1);cube.castShadow = true;cube.userData = { interactive: true,originalPosition: cube.position.clone(),hovered: false};scene.add(cube);// 创建更多测试物体for (let i = 0; i < 5; i++) {const sphereGeometry = new THREE.SphereGeometry(0.3, 16, 16);const sphereMaterial = new THREE.MeshStandardMaterial({color: new THREE.Color().setHSL(i / 5, 0.8, 0.6),metalness: 0.2,roughness: 0.7});const sphere = new THREE.Mesh(sphereGeometry, sphereMaterial);sphere.position.set((i - 2) * 1.2,0.3,-2);sphere.castShadow = true;sphere.userData = { interactive: true };scene.add(sphere);}};// 创建边界指示const createBoundaryIndicator = () => {const boundaryGeometry = new THREE.RingGeometry(1.5, 1.8, 32);const boundaryMaterial = new THREE.MeshBasicMaterial({color: 0x00ffff,transparent: true,opacity: 0.3,side: THREE.DoubleSide});const boundary = new THREE.Mesh(boundaryGeometry, boundaryMaterial);boundary.rotation.x = -Math.PI / 2;boundary.position.y = 0.05;boundary.visible = false; // 默认隐藏boundary.name = 'boundary';scene.add(boundary);};// 设置XR控制器const setupXRControllers = () => {const controllerModelFactory = new XRControllerModelFactory();// 创建左右手控制器for (let i = 0; i < 2; i++) {const controller = renderer.xr.getController(i);controller.addEventListener('selectstart', onSelectStart);controller.addEventListener('selectend', onSelectEnd);controller.addEventListener('squeezestart', onSqueezeStart);controller.addEventListener('squeezeend', onSqueezeEnd);controller.addEventListener('connected', onControllerConnected);controller.addEventListener('disconnected', onControllerDisconnected);// 添加控制器模型const controllerGrip = renderer.xr.getControllerGrip(i);controllerGrip.add(controllerModelFactory.createControllerModel(controllerGrip));scene.add(controller);scene.add(controllerGrip);controllers.push(controller);// 创建射线指示器const geometry = new THREE.BufferGeometry().setFromPoints([new THREE.Vector3(0, 0, 0),new THREE.Vector3(0, 0, -1)]);const line = new THREE.Line(geometry);line.name = 'line';line.scale.z = 5;line.visible = false;controller.add(line);}};// 控制器事件处理const onSelectStart = (event) => {const controller = event.target;const intersections = getControllerIntersections(controller);if (intersections.length > 0) {const object = intersections[0].object;if (object.userData.interactive) {// 抓取物体逻辑object.userData.grabbed = true;object.userData.controller = controller;object.userData.offset = new THREE.Vector3().copy(object.position).sub(controller.position);}}};const onSelectEnd = (event) => {// 释放抓取的物体scene.traverse(object => {if (object.userData.grabbed) {object.userData.grabbed = false;object.userData.controller = null;}});};const onSqueezeStart = (event) => {// 传送功能const controller = event.target;const intersections = getControllerIntersections(controller, true);if (intersections.length > 0) {const hitPoint = intersections[0].point;teleportPlayer(hitPoint);}};const onSqueezeEnd = (event) => {// 传送结束};const onControllerConnected = (event) => {const controller = event.target;console.log('控制器已连接:', event.data);controllerCount.value++;// 显示射线指示器const line = controller.getObjectByName('line');if (line) {line.visible = true;}};const onControllerDisconnected = (event) => {const controller = event.target;console.log('控制器已断开连接');controllerCount.value--;// 隐藏射线指示器const line = controller.getObjectByName('line');if (line) {line.visible = false;}};// 获取控制器射线交点const getControllerIntersections = (controller, floorOnly = false) => {const tempMatrix = new THREE.Matrix4();tempMatrix.identity().extractRotation(controller.matrixWorld);const raycaster = new THREE.Raycaster();raycaster.ray.origin.setFromMatrixPosition(controller.matrixWorld);raycaster.ray.direction.set(0, 0, -1).applyMatrix4(tempMatrix);const objects = floorOnly ? [scene.getObjectByName('floor')] : scene.children.filter(obj => obj.userData.interactive);return raycaster.intersectObjects(objects, false);};// 玩家传送const teleportPlayer = (position) => {if (xrReferenceSpace) {// 计算相对于参考空间的偏移const offsetPosition = new THREE.Vector3(-position.x,-position.y,-position.z);// 创建新的参考空间const newReferenceSpace = xrReferenceSpace.getOffsetReferenceSpace(new XRRigidTransform(offsetPosition));xrReferenceSpace = newReferenceSpace;renderer.xr.setReferenceSpace(xrReferenceSpace);}};// 进入VR模式const enterVR = async () => {if (!canEnterVR.value) return;isLoading.value = true;loadingStatus.value = '启动VR会话...';try {const session = await navigator.xr.requestSession('immersive-vr', {optionalFeatures: ['local-floor', 'bounded-floor', 'hand-tracking']});await setupXRSession(session);} catch (error) {console.error('进入VR失败:', error);isLoading.value = false;}};// 进入AR模式const enterAR = async () => {if (!canEnterAR.value) return;isLoading.value = true;loadingStatus.value = '启动AR会话...';try {const session = await navigator.xr.requestSession('immersive-ar', {optionalFeatures: ['hit-test', 'dom-overlay']});await setupXRSession(session);} catch (error) {console.error('进入AR失败:', error);isLoading.value = false;}};// 设置XR会话const setupXRSession = async (session) => {xrSession = session;isXRSessionActive.value = true;// 设置会话事件监听session.addEventListener('end', onXRSessionEnd);session.addEventListener('visibilitychange', onXRVisibilityChange);// 设置参考空间xrReferenceSpace = await session.requestReferenceSpace('local-floor');// 连接渲染器await renderer.xr.setSession(session);// 显示边界指示const boundary = scene.getObjectByName('boundary');if (boundary) {boundary.visible = true;}isLoading.value = false;};// 退出XRconst exitXR = async () => {if (xrSession) {await xrSession.end();}};// XR会话事件处理const onXRSessionEnd = () => {isXRSessionActive.value = false;xrSession = null;xrReferenceSpace = null;// 隐藏边界指示const boundary = scene.getObjectByName('boundary');if (boundary) {boundary.visible = false;}console.log('XR会话已结束');};const onXRVisibilityChange = () => {console.log('XR可见性变化:', xrSession.visibilityState);};// 更新函数const update = (deltaTime) => {// 更新控制器状态updateControllers();// 更新抓取的物体updateGrabbedObjects();// 更新性能统计updatePerformanceStats(deltaTime);};// 更新控制器状态const updateControllers = () => {controllers.forEach(controller => {const line = controller.getObjectByName('line');if (line && line.visible) {const intersections = getControllerIntersections(controller);// 更新射线长度和颜色if (intersections.length > 0) {line.scale.z = intersections[0].distance;line.material.color.set(intersections[0].object.userData.hovered ? 0x00ff00 : 0xffffff);} else {line.scale.z = 5;line.material.color.set(0xffffff);}}});};// 更新抓取的物体const updateGrabbedObjects = () => {scene.traverse(object => {if (object.userData.grabbed && object.userData.controller) {const controller = object.userData.controller;const worldPos = new THREE.Vector3();controller.getWorldPosition(worldPos);object.position.copy(worldPos).add(object.userData.offset);}});};// 更新性能统计const updatePerformanceStats = (deltaTime) => {frameCount++;lastFpsUpdate += deltaTime;if (lastFpsUpdate >= 1.0) {currentFPS.value = Math.round(frameCount / lastFpsUpdate);currentDrawCalls.value = renderer.info.render.calls;frameCount = 0;lastFpsUpdate = 0;}};// 动画循环const animate = () => {requestAnimationFrame(animate);const deltaTime = clock.getDelta();if (!isXRSessionActive) {controls.update();}update(deltaTime);if (renderer.xr.isPresenting) {renderer.render(scene, camera);} else {renderer.render(scene, camera);}};// 响应式设置watch(renderScale, (newScale) => {if (renderer.xr) {renderer.xr.setRenderTargetScale(newScale);}});watch(msaaEnabled, (newValue) => {if (renderer) {renderer.antialias = newValue;renderer.dispose();renderer.setSize(window.innerWidth, window.innerHeight);}});// 资源清理const cleanup = () => {if (xrSession) {xrSession.end();}if (renderer) {renderer.dispose();}if (xrButton && xrButton.parentNode) {xrButton.parentNode.removeChild(xrButton);}};onMounted(() => {init();window.addEventListener('resize', handleResize);});onUnmounted(() => {cleanup();window.removeEventListener('resize', handleResize);});const handleResize = () => {if (!camera || !renderer) return;camera.aspect = window.innerWidth / window.innerHeight;camera.updateProjectionMatrix();renderer.setSize(window.innerWidth, window.innerHeight);};return {container,rendererCanvas,isXRSessionActive,xrSupport,xrDeviceType,canEnterVR,canEnterAR,isLoading,loadingStatus,renderScale,msaaEnabled,currentFPS,currentDrawCalls,controllerCount,enterVR,enterAR,exitXR};}
};
</script><style scoped>
.xr-container {width: 100%;height: 100vh;position: relative;overflow: hidden;
}.xr-canvas {width: 100%;height: 100%;display: block;
}.xr-controls {position: absolute;top: 0;left: 0;width: 100%;height: 100%;display: flex;justify-content: center;align-items: center;background: rgba(0, 0, 0, 0.7);backdrop-filter: blur(10px);
}.xr-control-panel {background: rgba(0, 0, 0, 0.9);padding: 2rem;border-radius: 15px;border: 1px solid rgba(255, 255, 255, 0.1);max-width: 400px;width: 90%;
}.xr-control-panel h2 {color: #00ffff;margin-bottom: 1.5rem;text-align: center;
}.device-status {margin-bottom: 1.5rem;
}.status-item {display: flex;justify-content: space-between;margin-bottom: 0.5rem;padding: 0.5rem;background: rgba(255, 255, 255, 0.05);border-radius: 5px;
}.status-value.supported {color: #00ff00;
}.session-buttons {display: flex;flex-direction: column;gap: 1rem;margin-bottom: 1.5rem;
}.xr-button {padding: 1rem;border: none;border-radius: 8px;font-size: 1.1rem;font-weight: bold;cursor: pointer;transition: all 0.3s ease;
}.xr-button:disabled {opacity: 0.5;cursor: not-allowed;
}.vr-button {background: linear-gradient(45deg, #667eea, #764ba2);color: white;
}.ar-button {background: linear-gradient(45deg, #f093fb, #f5576c);color: white;
}.quality-settings {border-top: 1px solid rgba(255, 255, 255, 0.1);padding-top: 1.5rem;
}.quality-settings h3 {color: #00ffff;margin-bottom: 1rem;font-size: 1rem;
}.setting-group {margin-bottom: 1rem;
}.setting-group label {display: block;margin-bottom: 0.5rem;color: #ccc;
}.setting-group input[type="range"] {width: 100%;
}.setting-group input[type="checkbox"] {margin-left: 0.5rem;
}.xr-session-info {position: absolute;top: 1rem;left: 1rem;background: rgba(0, 0, 0, 0.7);padding: 1rem;border-radius: 8px;backdrop-filter: blur(10px);
}.session-stats {display: flex;flex-direction: column;gap: 0.5rem;margin-bottom: 1rem;color: #00ffff;font-size: 0.9rem;
}.exit-button {padding: 0.5rem 1rem;background: rgba(255, 0, 0, 0.3);border: 1px solid rgba(255, 0, 0, 0.5);border-radius: 5px;color: white;cursor: pointer;transition: background 0.3s ease;
}.exit-button:hover {background: rgba(255, 0, 0, 0.5);
}.loading-overlay {position: absolute;top: 0;left: 0;width: 100%;height: 100%;background: rgba(0, 0, 0, 0.9);display: flex;justify-content: center;align-items: center;z-index: 1000;
}.loading-content {text-align: center;color: white;
}.spinner {width: 40px;height: 40px;border: 4px solid rgba(255, 255, 255, 0.1);border-left: 4px solid #00ffff;border-radius: 50%;animation: spin 1s linear infinite;margin: 0 auto 1rem;
}@keyframes spin {0% { transform: rotate(0deg); }100% { transform: rotate(360deg); }
}.loading-details {color: #00ffff;font-size: 0.9rem;margin-top: 0.5rem;
}
</style>

高级XR特性实现

手部追踪集成

class HandTrackingManager {constructor(renderer, scene) {this.renderer = renderer;this.scene = scene;this.handMeshes = new Map();this.isHandTracking = false;this.initHandModels();}async initHandModels() {// 加载手部模型const handGeometry = await this.createHandGeometry();const handMaterial = new THREE.MeshBasicMaterial({color: 0x00ffff,transparent: true,opacity: 0.8});// 创建左右手模型this.handMeshes.set('left', new THREE.Mesh(handGeometry, handMaterial));this.handMeshes.set('right', new THREE.Mesh(handGeometry, handMaterial));this.handMeshes.forEach(hand => {hand.visible = false;this.scene.add(hand);});}async enableHandTracking(session) {try {// 请求手部追踪功能await session.updateRenderState({optionalFeatures: ['hand-tracking']});// 监听手部追踪数据session.addEventListener('handtracking', this.onHandTracking.bind(this));this.isHandTracking = true;} catch (error) {console.warn('手部追踪不可用:', error);}}onHandTracking(event) {const { hands } = event.data;hands.forEach(hand => {const handMesh = this.handMeshes.get(hand.handedness);if (handMesh) {this.updateHandPose(handMesh, hand);}});}updateHandPose(handMesh, handData) {handMesh.visible = true;// 更新手部关节位置// 这里需要根据handData中的关节数据更新手部模型// 简化实现：只更新整体位置handMesh.position.fromArray(handData.joints[0].position);handMesh.quaternion.fromArray(handData.joints[0].rotation);}createHandGeometry() {// 创建简化手部模型const geometry = new THREE.BoxGeometry(0.05, 0.1, 0.02);return geometry;}
}

空间锚点与持久化

class SpatialAnchorManager {constructor() {this.anchors = new Map();this.persistentAnchors = new Set();}async createAnchor(position, rotation, persistent = false) {try {// 创建XR锚点const anchorPose = new XRRigidTransform(position, rotation);const anchor = await xrSession.createAnchor(anchorPose, xrReferenceSpace);const anchorData = {anchor,position: position.clone(),rotation: rotation.clone(),createdAt: Date.now(),persistent};this.anchors.set(anchor, anchorData);if (persistent) {this.persistentAnchors.add(anchor);this.savePersistentAnchors();}return anchor;} catch (error) {console.error('创建锚点失败:', error);return null;}}async restorePersistentAnchors() {const savedAnchors = this.loadPersistentAnchors();for (const anchorData of savedAnchors) {await this.createAnchor(new THREE.Vector3().fromArray(anchorData.position),new THREE.Quaternion().fromArray(anchorData.rotation),true);}}savePersistentAnchors() {const anchorsToSave = Array.from(this.persistentAnchors).map(anchor => {const data = this.anchors.get(anchor);return {position: data.position.toArray(),rotation: data.rotation.toArray(),createdAt: data.createdAt};});localStorage.setItem('xr_persistent_anchors', JSON.stringify(anchorsToSave));}loadPersistentAnchors() {const saved = localStorage.getItem('xr_persistent_anchors');return saved ? JSON.parse(saved) : [];}
}

注意事项与最佳实践

1. 性能优化关键点

   • 维持稳定的90FPS帧率
   • 使用实例化渲染减少draw calls
   • 实现基于视口的LOD系统
   • 优化着色器复杂度

2. 用户体验最佳实践

   • 提供舒适的移动机制（传送/连续移动）
   • 实现适当的运动模糊和减震效果
   • 提供清晰的用户界面和反馈
   • 处理VR不适症（VR sickness）的缓解措施

3. 设备兼容性处理

   • 检测设备能力并自适应调整
   • 提供多种输入方式支持
   • 处理不同设备的渲染特性差异

下一节预告

第26节：GPU加速计算与Compute Shader探索
将深入探讨WebGPU技术在现代浏览器中的应用，包括：Compute Shader原理、GPU并行计算、物理模拟加速、以及如何利用GPU进行通用计算来提升3D应用的性能和视觉效果。
