EPM240T100I5N Altera FPGA MAX II CPLD
EPM240T100I5N Altera 阿尔特拉 MAX II 系列 CPLD（复杂可编程逻辑器件）中的一款产品。它并不是传统意义上的 FPGA，而是定位于低功耗、低成本、快速配置的可编程逻辑器件。该器件内部采用基于 EEPROM 的非易失性配置结构，因此在掉电后仍能保持逻辑功能，不需要额外的外部配置存储器。对于一些体积受限、功耗敏感的应用场景，它能够提供更为简洁和高效的逻辑扩展方案。
EPM240T100I5N 提供了约 240 个逻辑单元，采用高效的查找表和宏单元架构来实现组合逻辑与简单的时序逻辑。逻辑资源在规模上虽不及大型 FPGA，但对于中小规模逻辑控制、状态机实现、接口桥接、地址解码等任务非常合适。其引脚数为 100，封装形式为 TQFP，便于在对成本和 PCB 布局敏感的产品中使用。同时，-5 的速度等级表示其在 MAX II 系列中属于较快的速度档，适合需要较高运行频率和较低逻辑延迟的场合。器件等级为工业级，可在更宽的温度范围内稳定运行，满足工业控制和严苛环境下的应用需求。
在功能特性上，EPM240T100I5N 最大的优势是上电即运行，不需要像 SRAM 架构 FPGA 那样依赖外部配置 PROM；其低功耗特性使得待机电流极低，非常适合便携式或节能型系统；其设计流程简洁，通过 Quartus II 等设计软件就可以快速实现逻辑描述、综合、布线与烧录，开发门槛较低。在 I/O 接口方面，它支持多种电压标准，并且具备灵活的引脚分配能力，方便与其他芯片、MCU 或专用器件进行通信。
在实际应用中，EPM240T100I5N 常用于通信设备中的简单协议处理和接口逻辑转换，用于工业自动化系统中的控制逻辑实现，用于消费电子中进行小规模逻辑整合，还能作为 ASIC 辅助逻辑扩展的经济型替代方案。由于其稳定性高、成本低、无需外部配置器件、功耗低等特点，它被广泛用于对逻辑资源需求有限但又要求快速开发和可靠性的场合。
