架构评审：构建稳定、高效、可扩展的技术架构（下）

ops 2025/8/29 6:54:51

图片来源网络，侵权联系删

以下架构评审根据的实际经验梳理的一份清单，希望能够对你有所帮助。

在这里插入图片描述

架构评审：构建稳定、高效、可扩展的技术架构（上）

6. 弹性处理：应对异常，保障系统稳定

弹性处理是架构评审中不可或缺的一环。

  • 通过消息队列的幂等性设计，确保了消息重复消费与接口重复调用时业务的正确性。
  • 同时，引入了服务降级机制，对于非核心业务，在系统负载过高时自动降级，优先保障核心业务的正常运行。

例如，在支付接口出现故障时，自动切换至备用支付渠道，并向用户展示友好的提示信息，确保交易流程的顺畅进行。

  • 还实现了服务的超时熔断、异常熔断与限流熔断功能，当某个服务出现故障或响应时间过长时，熔断机制会自动触发，阻止故障的进一步扩散。熔断后，通过隔离故障服务，确保单一服务故障不会影响全局系统的稳定运行。

架构示例图

消息队列
备用服务
非核心服务
核心服务
API网关
客户端
消息队列
消息处理器
备用服务
备用服务1
备用服务2
非核心服务
服务3
服务4
核心服务
服务1
服务2
API网关
限流器
熔断器
客户端

架构示例代码

// 弹性处理系统实现
public class ResilientSystem {// 熔断器状态public enum CircuitState {CLOSED,    // 关闭状态，正常调用OPEN,      // 开启状态，直接返回错误HALF_OPEN  // 半开状态，尝试恢复}// 熔断器实现public static class CircuitBreaker {private CircuitState state;private int failureCount;private int failureThreshold;private long timeout;private long lastFailureTime;public CircuitBreaker(int failureThreshold, long timeout) {this.state = CircuitState.CLOSED;this.failureCount = 0;this.failureThreshold = failureThreshold;this.timeout = timeout;this.lastFailureTime = 0;}public synchronized boolean allowRequest() {if (state == CircuitState.OPEN) {// 检查是否超时，可以尝试半开状态if (System.currentTimeMillis() - lastFailureTime > timeout) {state = CircuitState.HALF_OPEN;return true;}return false;}return true;}public synchronized void recordSuccess() {if (state == CircuitState.HALF_OPEN) {state = CircuitState.CLOSED;failureCount = 0;}}public synchronized void recordFailure() {failureCount++;lastFailureTime = System.currentTimeMillis();if (failureCount >= failureThreshold) {state = CircuitState.OPEN;}}public CircuitState getState() {return state;}}// 限流器实现public static class RateLimiter {private int maxRequests;private long windowSize;private Deque<Long> requestTimestamps;public RateLimiter(int maxRequests, long windowSize) {this.maxRequests = maxRequests;this.windowSize = windowSize;this.requestTimestamps = new ArrayDeque<>();}public synchronized boolean allowRequest() {long currentTime = System.currentTimeMillis();// 移除过期的请求时间戳while (!requestTimestamps.isEmpty() && currentTime - requestTimestamps.peekFirst() > windowSize) {requestTimestamps.pollFirst();}// 检查是否超过限制if (requestTimestamps.size() >= maxRequests) {return false;}// 记录当前请求时间戳requestTimestamps.addLast(currentTime);return true;}}// 服务降级处理器public static class ServiceDegradationHandler {private Map<String, Boolean> serviceStates;private Map<String, Runnable> fallbackHandlers;public ServiceDegradationHandler() {this.serviceStates = new ConcurrentHashMap<>();this.fallbackHandlers = new ConcurrentHashMap<>();}public void registerService(String serviceName, Runnable fallbackHandler) {serviceStates.put(serviceName, true); // 默认服务正常fallbackHandlers.put(serviceName, fallbackHandler);}public void markServiceDown(String serviceName) {serviceStates.put(serviceName, false);}public void markServiceUp(String serviceName) {serviceStates.put(serviceName, true);}public Object handleRequest(String serviceName, Supplier<Object> serviceCall) {if (!isServiceAvailable(serviceName)) {System.out.println("服务 " + serviceName + " 不可用，执行降级处理");return fallbackHandlers.get(serviceName).run();}try {return serviceCall.get();} catch (Exception e) {System.out.println("服务 " + serviceName + " 调用失败，执行降级处理: " + e.getMessage());return fallbackHandlers.get(serviceName).run();}}private boolean isServiceAvailable(String serviceName) {return serviceStates.getOrDefault(serviceName, false);}}// 幂等消息处理器public static class IdempotentMessageProcessor {private Set<String> processedMessages;private MessageQueue messageQueue;public IdempotentMessageProcessor(MessageQueue messageQueue) {this.processedMessages = ConcurrentHashMap.newKeySet();this.messageQueue = messageQueue;}public void processMessage(Message message) {// 检查消息是否已处理if (processedMessages.contains(message.getId())) {System.out.println("消息 " + message.getId() + " 已处理，跳过");return;}try {// 处理消息System.out.println("处理消息: " + message.getId());// 模拟处理逻辑Thread.sleep(100);// 标记消息为已处理processedMessages.add(message.getId());// 模拟处理成功，从队列中移除messageQueue.ackMessage(message.getId());} catch (Exception e) {System.out.println("处理消息失败: " + e.getMessage());// 模拟重试messageQueue.retryMessage(message);}}}// 消息队列public static class MessageQueue {private BlockingQueue<Message> queue;private Map<String, Message> pendingMessages;public MessageQueue() {this.queue = new LinkedBlockingQueue<>();this.pendingMessages = new ConcurrentHashMap<>();}public void enqueue(Message message) {queue.add(message);pendingMessages.put(message.getId(), message);}public Message dequeue() throws InterruptedException {return queue.take();}public void ackMessage(String messageId) {pendingMessages.remove(messageId);}public void retryMessage(Message message) {// 模拟重试逻辑System.out.println("重试消息: " + message.getId());enqueue(message);}public int getPendingCount() {return pendingMessages.size();}}// 消息实体public static class Message {private String id;private String content;public Message(String id, String content) {this.id = id;this.content = content;}public String getId() {return id;}public String getContent() {return content;}}// 服务接口public interface Service {Object call() throws Exception;}// 核心服务实现public static class CoreService implements Service {@Overridepublic Object call() throws Exception {// 模拟核心服务调用Thread.sleep(50);return "核心服务响应";}}// 非核心服务实现public static class NonCoreService implements Service {@Overridepublic Object call() throws Exception {// 模拟非核心服务调用Thread.sleep(100);return "非核心服务响应";}}// 备用服务实现public static class BackupService implements Service {@Overridepublic Object call() throws Exception {// 模拟备用服务调用Thread.sleep(30);return "备用服务响应";}}// 客户端public static class Client {private CircuitBreaker circuitBreaker;private RateLimiter rateLimiter;private ServiceDegradationHandler degradationHandler;public Client(CircuitBreaker circuitBreaker, RateLimiter rateLimiter, ServiceDegradationHandler degradationHandler) {this.circuitBreaker = circuitBreaker;this.rateLimiter = rateLimiter;this.degradationHandler = degradationHandler;}public Object requestService(String serviceName, Service service) {// 检查熔断器状态if (!circuitBreaker.allowRequest()) {System.out.println("熔断器开启，请求被拒绝");return "服务不可用，请稍后再试";}// 检查限流if (!rateLimiter.allowRequest()) {System.out.println("请求被限流");return "请求过于频繁，请稍后再试";}try {// 调用服务Object result = degradationHandler.handleRequest(serviceName, service::call);// 记录成功circuitBreaker.recordSuccess();return result;} catch (Exception e) {// 记录失败circuitBreaker.recordFailure();throw e;}}}// 主方法 - 演示弹性处理系统public static void main(String[] args) throws InterruptedException {// 创建熔断器（失败阈值5次，超时时间5000毫秒）CircuitBreaker circuitBreaker = new CircuitBreaker(5, 5000);// 创建限流器（每秒最多10个请求）RateLimiter rateLimiter = new RateLimiter(10, 1000);// 创建服务降级处理器ServiceDegradationHandler degradationHandler = new ServiceDegradationHandler();// 注册服务和降级处理器degradationHandler.registerService("core-service", () -> {System.out.println("核心服务降级处理");return "核心服务降级响应";});degradationHandler.registerService("non-core-service", () -> {System.out.println("非核心服务降级处理");return "非核心服务降级响应";});degradationHandler.registerService("payment-service", () -> {System.out.println("支付服务降级处理 - 使用备用支付渠道");return "备用支付渠道响应";});// 创建客户端Client client = new Client(circuitBreaker, rateLimiter, degradationHandler);// 创建消息队列和处理器MessageQueue messageQueue = new MessageQueue();IdempotentMessageProcessor messageProcessor = new IdempotentMessageProcessor(messageQueue);// 模拟消息处理for (int i = 1; i <= 10; i++) {messageQueue.enqueue(new Message("msg-" + i, "消息内容 " + i));}// 启动消息处理线程new Thread(() -> {try {while (true) {Message message = messageQueue.dequeue();messageProcessor.processMessage(message);Thread.sleep(200);}} catch (InterruptedException e) {Thread.currentThread().interrupt();}}).start();// 模拟正常请求System.out.println("\n=== 正常请求测试 ===");for (int i = 0; i < 5; i++) {Object result = client.requestService("core-service", new CoreService());System.out.println("响应: " + result);Thread.sleep(100);}// 模拟服务故障System.out.println("\n=== 服务故障测试 ===");// 标记核心服务为不可用degradationHandler.markServiceDown("core-service");for (int i = 0; i < 5; i++) {Object result = client.requestService("core-service", new CoreService());System.out.println("响应: " + result);Thread.sleep(100);}// 模拟非核心服务请求System.out.println("\n=== 非核心服务请求测试 ===");for (int i = 0; i < 5; i++) {Object result = client.requestService("non-core-service", new NonCoreService());System.out.println("响应: " + result);Thread.sleep(100);}// 模拟限流System.out.println("\n=== 限流测试 ===");for (int i = 0; i < 15; i++) {Object result = client.requestService("core-service", new CoreService());System.out.println("响应: " + result);Thread.sleep(50);}// 模拟熔断System.out.println("\n=== 熔断测试 ===");// 模拟连续失败触发熔断for (int i = 0; i < 10; i++) {try {Object result = client.requestService("core-service", () -> {throw new RuntimeException("模拟服务故障");});System.out.println("响应: " + result);} catch (Exception e) {System.out.println("异常: " + e.getMessage());}Thread.sleep(100);}// 检查熔断器状态System.out.println("熔断器状态: " + circuitBreaker.getState());// 模拟熔断恢复System.out.println("\n=== 熔断恢复测试 ===");Thread.sleep(6000); // 等待超时for (int i = 0; i < 3; i++) {Object result = client.requestService("core-service", new CoreService());System.out.println("响应: " + result);Thread.sleep(100);}// 检查最终消息处理状态System.out.println("\n=== 消息处理状态 ===");System.out.println("待处理消息数: " + messageQueue.getPendingCount());}
}

7. 兼容性：确保系统协同，降低升级成本

对上下游系统进行了全面梳理，明确了各系统的依赖关系与影响范围。
在这里插入图片描述

  • 在新老系统替换过程中，采用了灰度发布策略，先将新系统与老系统并行运行，逐步将流量切换至新系统，确保新老系统能够来回切换，降低切换风险。

  • 同时，对数据存储进行了兼容性设计，使得新系统能够兼容老数据的读取与处理。

  • 在对上下游系统有影响的升级过程中，提前与相关业务方进行沟通，制定了详细的升级方案，通过批量处理、数据迁移等手段，将升级成本降至最低。

例如，在一次数据库升级过程中，通过在线热迁移技术，将数据从旧数据库平滑迁移到新数据库，整个过程对业务无任何影响。

架构示例图

数据迁移
灰度发布控制
兼容层
新系统
老系统
数据迁移
增量迁移
全量迁移
灰度发布控制
流量分配
监控
兼容层
API适配器
数据适配器
新系统
新数据库
老系统
旧数据库

架构示例代码

// 兼容性系统实现
public class CompatibilitySystem {// 系统版本枚举public enum SystemVersion {V1,  // 老版本V2   // 新版本}// 数据模型public static class DataModel {private String id;private String name;private Map<String, Object> attributes;public DataModel(String id, String name) {this.id = id;this.name = name;this.attributes = new HashMap<>();}public String getId() { return id; }public String getName() { return name; }public Map<String, Object> getAttributes() { return attributes; }public void addAttribute(String key, Object value) {attributes.put(key, value);}}// 数据存储接口public interface DataStorage {DataModel getData(String id);void saveData(DataModel data);}// 旧版数据存储public static class V1DataStorage implements DataStorage {private Map<String, DataModel> storage;public V1DataStorage() {this.storage = new HashMap<>();// 初始化一些测试数据DataModel user1 = new DataModel("user1", "张三");user1.addAttribute("age", 30);user1.addAttribute("email", "zhangsan@example.com");storage.put("user1", user1);DataModel user2 = new DataModel("user2", "李四");user2.addAttribute("age", 25);user2.addAttribute("email", "lisi@example.com");storage.put("user2", user2);}@Overridepublic DataModel getData(String id) {System.out.println("从V1数据存储获取数据: " + id);return storage.get(id);}@Overridepublic void saveData(DataModel data) {System.out.println("保存数据到V1数据存储: " + data.getId());storage.put(data.getId(), data);}}// 新版数据存储public static class V2DataStorage implements DataStorage {private Map<String, DataModel> storage;public V2DataStorage() {this.storage = new HashMap<>();// 新版数据模型包含更多字段DataModel user1 = new DataModel("user1", "张三");user1.addAttribute("age", 30);user1.addAttribute("email", "zhangsan@example.com");user1.addAttribute("phone", "13800138000");user1.addAttribute("address", "北京市海淀区");storage.put("user1", user1);DataModel user2 = new DataModel("user2", "李四");user2.addAttribute("age", 25);user2.addAttribute("email", "lisi@example.com");user2.addAttribute("phone", "13900139000");user2.addAttribute("address", "上海市浦东新区");storage.put("user2", user2);}@Overridepublic DataModel getData(String id) {System.out.println("从V2数据存储获取数据: " + id);return storage.get(id);}@Overridepublic void saveData(DataModel data) {System.out.println("保存数据到V2数据存储: " + data.getId());storage.put(data.getId(), data);}}// 兼容层public static class CompatibilityLayer {private DataStorage v1Storage;private DataStorage v2Storage;private SystemVersion currentVersion;public CompatibilityLayer(DataStorage v1Storage, DataStorage v2Storage) {this.v1Storage = v1Storage;this.v2Storage = v2Storage;this.currentVersion = SystemVersion.V1; // 初始使用V1}public void switchVersion(SystemVersion version) {this.currentVersion = version;System.out.println("系统切换到版本: " + version);}public DataModel getData(String id) {// 根据当前版本决定从哪个存储获取数据if (currentVersion == SystemVersion.V1) {return v1Storage.getData(id);} else {return v2Storage.getData(id);}}public void saveData(DataModel data) {// 根据当前版本决定保存到哪个存储if (currentVersion == SystemVersion.V1) {// 新数据保存时需要兼容旧格式DataModel compatibleData = convertToV1Format(data);v1Storage.saveData(compatibleData);} else {v2Storage.saveData(data);}}private DataModel convertToV1Format(DataModel data) {// 将新格式数据转换为旧格式DataModel v1Data = new DataModel(data.getId(), data.getName());v1Data.addAttribute("age", data.getAttributes().get("age"));v1Data.addAttribute("email", data.getAttributes().get("email"));return v1Data;}}// 灰度发布控制器public static class GrayReleaseController {private double v1TrafficRatio;private double v2TrafficRatio;private Random random;public GrayReleaseController() {this.v1TrafficRatio = 1.0; // 初始全部流量到V1this.v2TrafficRatio = 0.0;this.random = new Random();}public void setTrafficRatio(double v1Ratio, double v2Ratio) {this.v1TrafficRatio = v1Ratio;this.v2TrafficRatio = v2Ratio;System.out.println("设置流量比例: V1=" + (v1Ratio * 100) + "%, V2=" + (v2Ratio * 100) + "%");}public SystemVersion determineVersion() {double value = random.nextDouble();if (value < v1TrafficRatio) {return SystemVersion.V1;} else {return SystemVersion.V2;}}public void graduallyShiftTraffic(int steps, int delayMs) throws InterruptedException {double stepSize = 0.1 / steps;for (int i = 0; i < steps; i++) {v1TrafficRatio -= stepSize;v2TrafficRatio += stepSize;System.out.println("第 " + (i + 1) + " 步: V1=" + (v1TrafficRatio * 100) + "%, V2=" + (v2TrafficRatio * 100) + "%");Thread.sleep(delayMs);}}}// 数据迁移服务public static class DataMigrationService {private V1DataStorage v1Storage;private V2DataStorage v2Storage;public DataMigrationService(V1DataStorage v1Storage, V2DataStorage v2Storage) {this.v1Storage = v1Storage;this.v2Storage = v2Storage;}public void migrateData() {System.out.println("开始数据迁移...");// 获取所有V1数据for (String id : v1Storage.getStorage().keySet()) {DataModel v1Data = v1Storage.getData(id);// 转换为V2格式DataModel v2Data = convertToV2Format(v1Data);// 保存到V2存储v2Storage.saveData(v2Data);System.out.println("迁移数据: " + id);}System.out.println("数据迁移完成");}private DataModel convertToV2Format(DataModel v1Data) {// 将旧格式数据转换为新格式DataModel v2Data = new DataModel(v1Data.getId(), v1Data.getName());v2Data.addAttribute("age", v1Data.getAttributes().get("age"));v2Data.addAttribute("email", v1Data.getAttributes().get("email"));// 添加新字段（默认值）if (!v2Data.getAttributes().containsKey("phone")) {v2Data.addAttribute("phone", "未提供");}if (!v2Data.getAttributes().containsKey("address")) {v2Data.addAttribute("address", "未提供");}return v2Data;}}// API适配器public static class ApiAdapter {private CompatibilityLayer compatibilityLayer;private GrayReleaseController grayReleaseController;public ApiAdapter(CompatibilityLayer compatibilityLayer, GrayReleaseController grayReleaseController) {this.compatibilityLayer = compatibilityLayer;this.grayReleaseController = grayReleaseController;}public Object handleRequest(String requestId, String action, Map<String, Object> params) {// 根据灰度发布策略决定使用哪个版本SystemVersion version = grayReleaseController.determineVersion();System.out.println("请求 " + requestId + " 将由 " + version + " 处理");try {if ("getUser".equals(action)) {String userId = (String) params.get("userId");DataModel user = compatibilityLayer.getData(userId);return user;} else if ("saveUser".equals(action)) {String userId = (String) params.get("userId");String name = (String) params.get("name");int age = (Integer) params.get("age");String email = (String) params.get("email");DataModel user = new DataModel(userId, name);user.addAttribute("age", age);user.addAttribute("email", email);compatibilityLayer.saveData(user);return "用户保存成功";}return "未知操作";} catch (Exception e) {return "处理请求失败: " + e.getMessage();}}}// 主方法 - 演示兼容性系统public static void main(String[] args) throws InterruptedException {// 创建数据存储V1DataStorage v1Storage = new V1DataStorage();V2DataStorage v2Storage = new V2DataStorage();// 创建兼容层CompatibilityLayer compatibilityLayer = new CompatibilityLayer(v1Storage, v2Storage);// 创建灰度发布控制器GrayReleaseController grayReleaseController = new GrayReleaseController();// 创建数据迁移服务DataMigrationService migrationService = new DataMigrationService(v1Storage, v2Storage);// 创建API适配器ApiAdapter apiAdapter = new ApiAdapter(compatibilityLayer, grayReleaseController);// 测试初始状态（全部使用V1）System.out.println("=== 初始状态测试（全部使用V1） ===");Object result1 = apiAdapter.handleRequest("req1", "getUser", Map.of("userId", "user1"));System.out.println("响应: " + result1);// 执行数据迁移System.out.println("\n=== 数据迁移测试 ===");migrationService.migrateData();// 测试灰度发布System.out.println("\n=== 灰度发布测试 ===");// 初始状态：100% V1grayReleaseController.setTrafficRatio(1.0, 0.0);for (int i = 0; i < 5; i++) {Object result = apiAdapter.handleRequest("req" + i, "getUser", Map.of("userId", "user1"));System.out.println("响应: " + result);}// 逐步切换流量到V2System.out.println("\n逐步切换流量到V2...");grayReleaseController.graduallyShiftTraffic(5, 1000);// 测试新版本System.out.println("\n=== 新版本测试 ===");grayReleaseController.setTrafficRatio(0.0, 1.0);for (int i = 0; i < 5; i++) {Object result = apiAdapter.handleRequest("req" + i, "getUser", Map.of("userId", "user1"));System.out.println("响应: " + result);}// 测试数据保存（兼容性）System.out.println("\n=== 数据保存兼容性测试 ===");Object saveResult = apiAdapter.handleRequest("saveReq", "saveUser", Map.of("userId", "user3", "name", "王五", "age", 28, "email", "wangwu@example.com"));System.out.println("响应: " + saveResult);// 验证数据保存后的兼容性Object getResult = apiAdapter.handleRequest("getReq", "getUser", Map.of("userId", "user3"));System.out.println("获取保存的数据: " + getResult);// 测试版本切换System.out.println("\n=== 版本切换测试 ===");compatibilityLayer.switchVersion(SystemVersion.V2);Object getResultV2 = apiAdapter.handleRequest("getReqV2", "getUser", Map.of("userId", "user1"));System.out.println("V2版本获取数据: " + getResultV2);compatibilityLayer.switchVersion(SystemVersion.V1);Object getResultV1 = apiAdapter.handleRequest("getReqV1", "getUser", Map.of("userId", "user1"));System.out.println("V1版本获取数据: " + getResultV1);}
}

8. 安全性：筑牢防线，守护数据资产

安全性是架构评审中的重中之重。从多个层面构建了安全防护体系。

  • 在代码层面，严格执行SQL注入与XSS攻击的防范措施，对用户输入进行严格的过滤与验证。

  • 在数据层面，实施了数据加密存储与传输，确保数据在各个环节的安全性。

  • 在接口层面，引入了防刷保护机制，通过限流、验证码等手段，防止恶意攻击。

  • 在权限控制方面，建立了精细的访问控制策略，对数据与功能权限进行严格限制，确保只有授权用户能够访问敏感信息。

  • 还对后台运营系统进行了日志审计，记录所有操作行为，以便在发生安全事件时能够快速追溯与定位。

通过这些安全措施，有效地降低了数据泄露与系统被攻击的风险，守护了公司的数据资产。

架构示例图

日志审计
数据层
业务服务
认证授权
安全网关
客户端
日志审计
ELK日志系统
数据库
数据加密
业务服务
权限中间件
认证授权
认证服务
授权服务
令牌管理
安全网关
请求限流
验证码
Web应用防火墙
客户端

架构示例代码

// 安全系统实现
public class SecuritySystem {// SQL注入防护public static class SqlInjectionProtection {private static final String[] SQL_INJECTION_PATTERNS = {"SELECT", "INSERT", "UPDATE", "DELETE", "DROP", "UNION", "EXEC", "EXECUTE", "xp_", "--", "/*", "*/", ";"};public static String sanitizeInput(String input) {if (input == null) {return null;}String sanitized = input;// 移除潜在的SQL注入字符for (String pattern : SQL_INJECTION_PATTERNS) {sanitized = sanitized.replaceAll("(?i)" + pattern, "");}// 使用预编译语句参数化查询return sanitized;}public static PreparedStatement createPreparedStatement(Connection conn, String sql, Object... params) throws SQLException {// 使用预编译语句防止SQL注入PreparedStatement stmt = conn.prepareStatement(sql);for (int i = 0; i < params.length; i++) {stmt.setObject(i + 1, params[i]);}return stmt;}}// XSS防护public static class XssProtection {private static final String[] XSS_PATTERNS = {"<script", "</script>", "javascript:", "onload=", "onerror=", "onfocus=", "onblur=", "onclick=", "onmouseover=", "onchange="};public static String sanitizeHtml(String input) {if (input == null) {return null;}String sanitized = input;// 移除潜在的XSS字符for (String pattern : XSS_PATTERNS) {sanitized = sanitized.replaceAll("(?i)" + pattern, "");}// HTML转义sanitized = sanitized.replace("&", "&amp;").replace("<", "&lt;").replace(">", "&gt;").replace("\"", "&quot;").replace("'", "&apos;");return sanitized;}}// 数据加密public static class DataEncryption {private static final String ALGORITHM = "AES";private static final String TRANSFORMATION = "AES/CBC/PKCS5Padding";private static final String SECRET_KEY = "ThisIsASecretKey123";private static final String IV = "ThisIsAnInitVec";public static String encrypt(String data) throws Exception {SecretKeySpec secretKey = new SecretKeySpec(SECRET_KEY.getBytes(), ALGORITHM);IvParameterSpec ivParameterSpec = new IvParameterSpec(IV.getBytes());Cipher cipher = Cipher.getInstance(TRANSFORMATION);cipher.init(Cipher.ENCRYPT_MODE, secretKey, ivParameterSpec);byte[] encrypted = cipher.doFinal(data.getBytes());return Base64.getEncoder().encodeToString(encrypted);}public static String decrypt(String encryptedData) throws Exception {SecretKeySpec secretKey = new SecretKeySpec(SECRET_KEY.getBytes(), ALGORITHM);IvParameterSpec ivParameterSpec = new IvParameterSpec(IV.getBytes());Cipher cipher = Cipher.getInstance(TRANSFORMATION);cipher.init(Cipher.DECRYPT_MODE, secretKey, ivParameterSpec);byte[] decoded = Base64.getDecoder().decode(encryptedData);byte[] decrypted = cipher.doFinal(decoded);return new String(decrypted);}}// 请求限流public static class RequestRateLimiter {private Map<String, Deque<Long>> userRequests;private int maxRequests;private long windowSize;public RequestRateLimiter(int maxRequests, long windowSize) {this.userRequests = new ConcurrentHashMap<>();this.maxRequests = maxRequests;this.windowSize = windowSize;}public boolean allowRequest(String userId) {Deque<Long> requests = userRequests.computeIfAbsent(userId, k -> new ArrayDeque<>());long currentTime = System.currentTimeMillis();// 移除过期的请求while (!requests.isEmpty() && currentTime - requests.peekFirst() > windowSize) {requests.pollFirst();}// 检查是否超过限制if (requests.size() >= maxRequests) {return false;}// 记录当前请求requests.addLast(currentTime);return true;}}// 验证码生成器public static class CaptchaGenerator {private static final String CHARACTERS = "ABCDEFGHJKLMNPQRSTUVWXYZabcdefghijkmnpqrstuvwxyz23456789";private static final int CAPTCHA_LENGTH = 6;public static String generateCaptcha() {Random random = new Random();StringBuilder captcha = new StringBuilder(CAPTCHA_LENGTH);for (int i = 0; i < CAPTCHA_LENGTH; i++) {captcha.append(CHARACTERS.charAt(random.nextInt(CHARACTERS.length())));}return captcha.toString();}public static boolean verifyCaptcha(String inputCaptcha, String storedCaptcha) {return inputCaptcha != null && inputCaptcha.equalsIgnoreCase(storedCaptcha);}}// 认证服务public static class AuthenticationService {private Map<String, String> userCredentials;private Map<String, String> userTokens;public AuthenticationService() {this.userCredentials = new ConcurrentHashMap<>();this.userTokens = new ConcurrentHashMap<>();// 初始化测试用户userCredentials.put("admin", "admin123");userCredentials.put("user1", "password1");}public String login(String username, String password) {if (userCredentials.containsKey(username) && userCredentials.get(username).equals(password)) {// 生成令牌String token = UUID.randomUUID().toString();userTokens.put(token, username);System.out.println("用户 " + username + " 登录成功");return token;}System.out.println("用户 " + username + " 登录失败");return null;}public boolean verifyToken(String token) {return userTokens.containsKey(token);}public String getUsernameByToken(String token) {return userTokens.get(token);}public void logout(String token) {userTokens.remove(token);System.out.println("用户已登出");}}// 授权服务public static class AuthorizationService {private Map<String, Set<String>> userPermissions;public AuthorizationService() {this.userPermissions = new ConcurrentHashMap<>();// 初始化用户权限Set<String> adminPermissions = new HashSet<>();adminPermissions.add("user:create");adminPermissions.add("user:read");adminPermissions.add("user:update");adminPermissions.add("user:delete");adminPermissions.add("system:admin");userPermissions.put("admin", adminPermissions);Set<String> userPermissions = new HashSet<>();userPermissions.add("user:read");userPermissions.add("user:update:own");userPermissions.add("order:create");userPermissions.add("order:read");userPermissions.add("order:update:own");userPermissions.add("order:delete:own");userPermissions.put("user1", userPermissions);}public boolean hasPermission(String username, String permission) {Set<String> permissions = userPermissions.get(username);return permissions != null && permissions.contains(permission);}public boolean hasAnyPermission(String username, String... permissions) {Set<String> userPerms = userPermissions.get(username);if (userPerms == null) {return false;}for (String permission : permissions) {if (userPerms.contains(permission)) {return true;}}return false;}public boolean hasAllPermissions(String username, String... permissions) {Set<String> userPerms = userPermissions.get(username);if (userPerms == null) {return false;}for (String permission : permissions) {if (!userPerms.contains(permission)) {return false;}}return true;}}// 日志审计public static class AuditLogger {private List<AuditLog> logs;public AuditLogger() {this.logs = new CopyOnWriteArrayList<>();}public void log(String username, String action, String resource, String details) {AuditLog log = new AuditLog(username,action,resource,details,new Date(),InetAddress.getLoopbackAddress().getHostAddress());logs.add(log);System.out.println("审计日志: " + log);}public List<AuditLog> getLogsForUser(String username) {return logs.stream().filter(log -> log.getUsername().equals(username)).collect(Collectors.toList());}public List<AuditLog> getLogsForResource(String resource) {return logs.stream().filter(log -> log.getResource().equals(resource)).collect(Collectors.toList());}public List<AuditLog> getLogsByTimeRange(Date startTime, Date endTime) {return logs.stream().filter(log -> !log.getTimestamp().before(startTime) && !log.getTimestamp().after(endTime)).collect(Collectors.toList());}}// 审计日志实体public static class AuditLog {private String username;private String action;private String resource;private String details;private Date timestamp;String ipAddress;public AuditLog(String username, String action, String resource, String details, Date timestamp, String ipAddress) {this.username = username;this.action = action;this.resource = resource;this.details = details;this.timestamp = timestamp;this.ipAddress = ipAddress;}// getter方法public String getUsername() { return username; }public String getAction() { return action; }public String getResource() { return resource; }public String getDetails() { return details; }public Date getTimestamp() { return timestamp; }public String getIpAddress() { return ipAddress; }@Overridepublic String toString() {return String.format("[%s] 用户 %s 执行了 %s 操作 on %s. 详情: %s. IP: %s",timestamp, username, action, resource, details, ipAddress);}}// 安全中间件public static class SecurityMiddleware {private AuthenticationService authService;private AuthorizationService authzService;private RequestRateLimiter rateLimiter;private AuditLogger auditLogger;public SecurityMiddleware(AuthenticationService authService, AuthorizationService authzService,RequestRateLimiter rateLimiter,AuditLogger auditLogger) {this.authService = authService;this.authzService = authzService;this.rateLimiter = rateLimiter;this.auditLogger = auditLogger;}public SecurityResponse checkRequest(String token, String userId, String action, String resource) {// 1. 检查令牌if (!authService.verifyToken(token)) {auditLogger.log(userId, "AUTH_FAILED", resource, "无效的访问令牌");return new SecurityResponse(false, "无效的访问令牌");}String username = authService.getUsernameByToken(token);// 2. 检查限流if (!rateLimiter.allowRequest(username)) {auditLogger.log(username, "RATE_LIMIT_EXCEEDED", resource, "请求频率超限");return new SecurityResponse(false, "请求频率超限，请稍后再试");}// 3. 检查权限String permission = resource + ":" + action;if (!authzService.hasPermission(username, permission)) {auditLogger.log(username, "PERMISSION_DENIED", resource, "权限不足");return new SecurityResponse(false, "权限不足");}// 4. 记录成功日志auditLogger.log(username, action, resource, "操作成功");return new SecurityResponse(true, "安全检查通过");}}// 安全响应public static class SecurityResponse {private boolean allowed;private String message;public SecurityResponse(boolean allowed, String message) {this.allowed = allowed;this.message = message;}public boolean isAllowed() { return allowed; }public String getMessage() { return message; }}// 主方法 - 演示安全系统public static void main(String[] args) throws Exception {// 创建安全组件AuthenticationService authService = new AuthenticationService();AuthorizationService authzService = new AuthorizationService();RequestRateLimiter rateLimiter = new RequestRateLimiter(10, 60000); // 每分钟10次请求AuditLogger auditLogger = new AuditLogger();// 创建安全中间件SecurityMiddleware securityMiddleware = new SecurityMiddleware(authService, authzService, rateLimiter, auditLogger);// 测试SQL注入防护System.out.println("=== SQL注入防护测试 ===");String maliciousInput = "SELECT * FROM users WHERE id = 1; DROP TABLE users;";String sanitizedInput = SqlInjectionProtection.sanitizeInput(maliciousInput);System.out.println("原始输入: " + maliciousInput);System.out.println("净化后输入: " + sanitizedInput);// 测试XSS防护System.out.println("\n=== XSS防护测试 ===");String xssInput = "<script>alert('XSS攻击')</script>";String sanitizedHtml = XssProtection.sanitizeHtml(xssInput);System.out.println("原始HTML: " + xssInput);System.out.println("净化后HTML: " + sanitizedHtml);// 测试数据加密System.out.println("\n=== 数据加密测试 ===");String sensitiveData = "用户敏感信息";String encrypted = DataEncryption.encrypt(sensitiveData);String decrypted = DataEncryption.decrypt(encrypted);System.out.println("原始数据: " + sensitiveData);System.out.println("加密后: " + encrypted);System.out.println("解密后: " + decrypted);// 测试验证码System.out.println("\n=== 验证码测试 ===");String captcha = CaptchaGenerator.generateCaptcha();System.out.println("生成的验证码: " + captcha);System.out.println("验证码验证: " + CaptchaGenerator.verifyCaptcha(captcha, captcha));// 测试认证授权System.out.println("\n=== 认证授权测试 ===");// 用户登录String token = authService.login("admin", "admin123");System.out.println("登录令牌: " + (token != null ? "成功" : "失败"));if (token != null) {// 检查权限boolean hasPermission = authzService.hasPermission("admin", "user:create");System.out.println("admin用户是否有创建用户权限: " + hasPermission);// 使用安全中间件检查请求SecurityResponse response = securityMiddleware.checkRequest(token, "admin", "create", "user");System.out.println("安全检查结果: " + response.getMessage());// 模拟无权限操作response = securityMiddleware.checkRequest(token, "admin", "delete", "user");System.out.println("无权限操作检查结果: " + response.getMessage());// 用户登出authService.logout(token);}// 测试请求限流System.out.println("\n=== 请求限流测试 ===");String testToken = authService.login("user1", "password1");if (testToken != null) {// 模拟多次请求for (int i = 0; i < 15; i++) {SecurityResponse response = securityMiddleware.checkRequest(testToken, "user1", "read", "product");System.out.println("请求 " + (i + 1) + ": " + response.getMessage());if (!response.isAllowed()) {break;}try {Thread.sleep(100); // 模拟请求间隔} catch (InterruptedException e) {Thread.currentThread().interrupt();}}authService.logout(testToken);}// 测试日志审计System.out.println("\n=== 日志审计测试 ===");// 模拟一些操作authService.login("admin", "admin123");auditLogger.log("admin", "read", "user", "查看用户列表");auditLogger.log("admin", "create", "user", "创建新用户");auditLogger.log("user1", "read", "order", "查看订单");// 查询特定用户的日志List<AuditLog> adminLogs = auditLogger.getLogsForUser("admin");System.out.println("\nadmin用户的操作日志:");adminLogs.forEach(System.out::println);// 查询特定资源的日志List<AuditLog> userLogs = auditLogger.getLogsForResource("user");System.out.println("\nuser资源的操作日志:");userLogs.forEach(System.out::println);}
}

9. 可测性：精准测试，确保系统质量

尽量缩小测试环境与线上的差异，确保测试结果能够真实反映线上系统的运行状态。

同时，支持在线上进行压测，但通过隔离测试数据、设置测试白名单等手段，避免对真实用户产生影响。在这里插入图片描述

例如，在一次线上压测中，通过模拟10万并发用户，对系统的性能进行了全面测试，及时发现了系统中的性能瓶颈，并进行了针对性优化。

此外，还支持部署多套隔离的测试环境，满足不同测试场景的需求。在测试过程中，合理分配黑盒测试与白盒测试的工作量，确保测试的全面性与深入性。
例如，对于核心业务逻辑，采用白盒测试，深入代码层面进行验证；对于系统接口与用户交互，采用黑盒测试，从用户视角进行测试。

通过这些可测性设计，能够精准定位系统中的问题，确保系统上线后的稳定运行。

架构示例图

测试策略
测试数据
测试工具
线上环境
测试环境
测试策略
黑盒测试
白盒测试
性能测试
安全测试
测试数据
测试数据生成器
测试数据管理
测试工具
单元测试框架
集成测试框架
系统测试框架
负载测试工具
线上环境
生产负载测试
隔离沙箱
测试环境
单元测试环境
集成测试环境
系统测试环境

架构示例代码

// 可测试系统实现
public class TestableSystem {// 业务服务接口public interface BusinessService {Result process(Request request);}// 请求对象public static class Request {private String id;private String type;private Map<String, Object> parameters;public Request(String id, String type) {this.id = id;this.type = type;this.parameters = new HashMap<>();}public String getId() { return id; }public String getType() { return type; }public Map<String, Object> getParameters() { return parameters; }public void addParameter(String key, Object value) {parameters.put(key, value);}}// 结果对象public static class Result {private boolean success;private String message;private Object data;public Result(boolean success, String message) {this(success, message, null);}public Result(boolean success, String message, Object data) {this.success = success;this.message = message;this.data = data;}public boolean isSuccess() { return success; }public String getMessage() { return message; }public Object getData() { return data; }}// 业务服务实现public static class OrderService implements BusinessService {private OrderRepository orderRepository;public OrderService(OrderRepository orderRepository) {this.orderRepository = orderRepository;}@Overridepublic Result process(Request request) {try {String orderId = request.getId();String userId = (String) request.getParameters().get("userId");BigDecimal amount = new BigDecimal((String) request.getParameters().get("amount"));// 验证订单if (orderId == null || orderId.isEmpty()) {return new Result(false, "订单ID不能为空");}if (userId == null || userId.isEmpty()) {return new Result(false, "用户ID不能为空");}if (amount == null || amount.compareTo(BigDecimal.ZERO) <= 0) {return new Result(false, "订单金额必须大于0");}// 创建订单Order order = new Order(orderId, userId, amount);orderRepository.save(order);return new Result(true, "订单创建成功", order);} catch (Exception e) {return new Result(false, "处理订单失败: " + e.getMessage());}}}// 订单仓库public interface OrderRepository {void save(Order order);Order findById(String orderId);List<Order> findByUserId(String userId);}// 内存订单仓库（用于测试）public static class InMemoryOrderRepository implements OrderRepository {private Map<String, Order> orders;public InMemoryOrderRepository() {this.orders = new ConcurrentHashMap<>();}@Overridepublic void save(Order order) {orders.put(order.getId(), order);}@Overridepublic Order findById(String orderId) {return orders.get(orderId);}@Overridepublic List<Order> findByUserId(String userId) {return orders.values().stream().filter(order -> order.getUserId().equals(userId)).collect(Collectors.toList());}public void clear() {orders.clear();}}// 订单实体public static class Order {private String id;private String userId;private BigDecimal amount;private Date createTime;public Order(String id, String userId, BigDecimal amount) {this.id = id;this.userId = userId;this.amount = amount;this.createTime = new Date();}public String getId() { return id; }public String getUserId() { return userId; }public BigDecimal getAmount() { return amount; }public Date getCreateTime() { return createTime; }}// 单元测试public static class UnitTest {private OrderService orderService;private InMemoryOrderRepository orderRepository;public UnitTest() {this.orderRepository = new InMemoryOrderRepository();this.orderService = new OrderService(orderRepository);}public void testOrderCreation() {// 测试正常订单创建Request request = new Request("order123", "create");request.addParameter("userId", "user123");request.addParameter("amount", "100.00");Result result = orderService.process(request);assert result.isSuccess() : "订单创建应该成功";assert result.getData() instanceof Order : "返回数据应该是Order对象";Order order = (Order) result.getData();assert order.getId().equals("order123") : "订单ID应该匹配";assert order.getUserId().equals("user123") : "用户ID应该匹配";assert order.getAmount().compareTo(new BigDecimal("100.00")) == 0 : "订单金额应该匹配";System.out.println("单元测试通过: 订单创建");}public void testInvalidOrderId() {// 测试无效订单IDRequest request = new Request("", "create");request.addParameter("userId", "user123");request.addParameter("amount", "100.00");Result result = orderService.process(request);assert !result.isSuccess() : "无效订单ID应该失败";assert result.getMessage().equals("订单ID不能为空") : "错误消息应该匹配";System.out.println("单元测试通过: 无效订单ID");}public void testInvalidAmount() {// 测试无效金额Request request = new Request("order123", "create");request.addParameter("userId", "user123");request.addParameter("amount", "-100.00");Result result = orderService.process(request);assert !result.isSuccess() : "无效金额应该失败";assert result.getMessage().equals("订单金额必须大于0") : "错误消息应该匹配";System.out.println("单元测试通过: 无效金额");}public void runAllTests() {orderRepository.clear();testOrderCreation();testInvalidOrderId();testInvalidAmount();System.out.println("所有单元测试通过");}}// 集成测试public static class IntegrationTest {private OrderService orderService;private InMemoryOrderRepository orderRepository;public IntegrationTest() {this.orderRepository = new InMemoryOrderRepository();this.orderService = new OrderService(orderRepository);}public void testOrderPersistence() {// 创建订单Request request = new Request("order123", "create");request.addParameter("userId", "user123");request.addParameter("amount", "100.00");Result result = orderService.process(request);assert result.isSuccess() : "订单创建应该成功";// 验证订单是否持久化Order savedOrder = orderRepository.findById("order123");assert savedOrder != null : "订单应该被持久化";assert savedOrder.getId().equals("order123") : "持久化的订单ID应该匹配";System.out.println("集成测试通过: 订单持久化");}public void testUserOrderQuery() {// 创建多个订单Request request1 = new Request("order1", "create");request1.addParameter("userId", "user123");request1.addParameter("amount", "100.00");orderService.process(request1);Request request2 = new Request("order2", "create");request2.addParameter("userId", "user123");request2.addParameter("amount", "200.00");orderService.process(request2);Request request3 = new Request("order3", "create");request3.addParameter("userId", "user456");request3.addParameter("amount", "150.00");orderService.process(request3);// 查询用户订单List<Order> userOrders = orderRepository.findByUserId("user123");assert userOrders.size() == 2 : "用户应该有2个订单";System.out.println("集成测试通过: 用户订单查询");}public void runAllTests() {orderRepository.clear();testOrderPersistence();testUserOrderQuery();System.out.println("所有集成测试通过");}}// 性能测试public static class PerformanceTest {private OrderService orderService;private InMemoryOrderRepository orderRepository;public PerformanceTest() {this.orderRepository = new InMemoryOrderRepository();this.orderService = new OrderService(orderRepository);}public void testConcurrentOrderCreation(int threadCount, int requestsPerThread) {ExecutorService executor = Executors.newFixedThreadPool(threadCount);CountDownLatch latch = new CountDownLatch(threadCount * requestsPerThread);long startTime = System.currentTimeMillis();// 提交并发请求for (int i = 0; i < threadCount; i++) {final int threadId = i;executor.submit(() -> {for (int j = 0; j < requestsPerThread; j++) {Request request = new Request("order-" + threadId + "-" + j, "create");request.addParameter("userId", "user-" + threadId);request.addParameter("amount", "100.00");Result result = orderService.process(request);assert result.isSuccess() : "订单创建应该成功";latch.countDown();}});}try {latch.await();long endTime = System.currentTimeMillis();double duration = (endTime - startTime) / 1000.0;double tps = (threadCount * requestsPerThread) / duration;System.out.println("性能测试结果:");System.out.println("线程数: " + threadCount);System.out.println("每线程请求数: " + requestsPerThread);System.out.println("总请求数: " + (threadCount * requestsPerThread));System.out.println("总耗时: " + duration + "秒");System.out.println("TPS: " + tps);// 验证所有订单都被创建int totalOrders = orderRepository.findByUserId("user-0").size() + orderRepository.findByUserId("user-1").size();assert totalOrders == (threadCount * requestsPerThread) : "所有订单都应该被创建";} catch (InterruptedException e) {Thread.currentThread().interrupt();} finally {executor.shutdown();}}public void runPerformanceTest() {orderRepository.clear();testConcurrentOrderCreation(10, 100); // 10个线程，每个线程100个请求System.out.println("性能测试完成");}}// 测试数据生成器public static class TestDataGenerator {private static final Random random = new Random();public static String generateOrderId() {return "order-" + System.currentTimeMillis() + "-" + random.nextInt(10000);}public static String generateUserId() {return "user-" + random.nextInt(10000);}public static String generateAmount() {return String.format("%.2f", 10 + random.nextDouble() * 1000);}public static Request generateOrderRequest() {Request request = new Request(generateOrderId(), "create");request.addParameter("userId", generateUserId());request.addParameter("amount", generateAmount());return request;}public static List<Request> generateOrderRequests(int count) {List<Request> requests = new ArrayList<>();for (int i = 0; i < count; i++) {requests.add(generateOrderRequest());}return requests;}}// 主方法 - 演示可测试系统public static void main(String[] args) {// 运行单元测试System.out.println("=== 运行单元测试 ===");UnitTest unitTest = new UnitTest();unitTest.runAllTests();// 运行集成测试System.out.println("\n=== 运行集成测试 ===");IntegrationTest integrationTest = new IntegrationTest();integrationTest.runAllTests();// 运行性能测试System.out.println("\n=== 运行性能测试 ===");PerformanceTest performanceTest = new PerformanceTest();performanceTest.runPerformanceTest();// 测试数据生成器演示System.out.println("\n=== 测试数据生成器演示 ===");List<Request> requests = TestDataGenerator.generateOrderRequests(5);for (Request request : requests) {System.out.println("生成的请求: ID=" + request.getId() + ", 用户ID=" + request.getParameters().get("userId") + ", 金额=" + request.getParameters().get("amount"));}}
}

10. 可运维性：简化运维，降低运营成本

可运维性关注系统在长期运行过程中的维护与管理。

为系统设计了初始化与预热环节，确保系统在启动时能够快速进入稳定状态。针对数据指数级别递增的问题，制定了定期归档策略，将历史数据迁移到低成本存储介质中，降低了存储成本。

同时，建立了完善的系统巡检与维护机制，定期对系统进行性能监控、日志分析与故障排查，及时发现并解决潜在问题。

例如，通过自动化脚本，每天凌晨对系统进行全量巡检，生成巡检报告，并将异常情况及时通知运维人员。

此外，还设计了业务运维的可视化界面，使运维人员能够直观地了解系统运行状态，快速定位问题根源，提高了运维效率，降低了运营成本。

架构示例图

存储系统
自动化工具
监控系统
运维系统
存储系统
热存储
冷存储
自动化工具
归档存储
自动化通知
监控系统
性能监控
日志监控
故障监控
运维系统
初始化系统
预热系统
数据归档系统
巡检系统
可视化分析

架构示例代码

// 可运维系统实现
public class OperableSystem {// 系统初始化服务public static class SystemInitializer {private List<SystemComponent> components;public SystemInitializer() {this.components = new ArrayList<>();}public void registerComponent(SystemComponent component) {components.add(component);}public void initialize() {System.out.println("开始系统初始化...");for (SystemComponent component : components) {try {System.out.println("初始化组件: " + component.getName());component.initialize();System.out.println("组件 " + component.getName() + " 初始化成功");} catch (Exception e) {System.err.println("组件 " + component.getName() + " 初始化失败: " + e.getMessage());throw new RuntimeException("系统初始化失败", e);}}System.out.println("系统初始化完成");}}// 系统预热服务public static class SystemWarmer {private List<SystemComponent> components;public SystemWarmer() {this.components = new ArrayList<>();}public void registerComponent(SystemComponent component) {components.add(component);}public void warmUp() {System.out.println("开始系统预热...");for (SystemComponent component : components) {try {System.out.println("预热组件: " + component.getName());component.warmUp();System.out.println("组件 " + component.getName() + " 预热完成");} catch (Exception e) {System.err.println("组件 " + component.getName() + " 预热失败: " + e.getMessage());}}System.out.println("系统预热完成");}}// 系统组件接口public interface SystemComponent {String getName();void initialize() throws Exception;void warmUp() throws Exception;void shutdown() throws Exception;}// 数据库组件public static class DatabaseComponent implements SystemComponent {private String name;private boolean initialized;public DatabaseComponent(String name) {this.name = name;this.initialized = false;}@Overridepublic String getName() {return name;}@Overridepublic void initialize() throws Exception {// 模拟数据库初始化System.out.println("初始化数据库连接池...");Thread.sleep(1000); // 模拟初始化耗时// 创建必要的表System.out.println("创建数据库表结构...");Thread.sleep(500);initialized = true;}@Overridepublic void warmUp() throws Exception {if (!initialized) {throw new IllegalStateException("数据库未初始化");}// 预热数据库连接System.out.println("预热数据库连接...");Thread.sleep(500);// 预加载常用数据System.out.println("预加载常用数据...");Thread.sleep(500);}@Overridepublic void shutdown() throws Exception {System.out.println("关闭数据库连接...");Thread.sleep(300);}}// 缓存组件public static class CacheComponent implements SystemComponent {private String name;private boolean initialized;public CacheComponent(String name) {this.name = name;this.initialized = false;}@Overridepublic String getName() {return name;}@Overridepublic void initialize() throws Exception {// 模拟缓存初始化System.out.println("初始化缓存连接...");Thread.sleep(800);initialized = true;}@Overridepublic void warmUp() throws Exception {if (!initialized) {throw new IllegalStateException("缓存未初始化");}// 预热缓存System.out.println("预热缓存数据...");Thread.sleep(1000);}@Overridepublic void shutdown() throws Exception {System.out.println("关闭缓存连接...");Thread.sleep(200);}}// 数据归档服务public static class DataArchivingService {private StorageSystem storageSystem;private DataArchivingPolicy policy;public DataArchivingService(StorageSystem storageSystem, DataArchivingPolicy policy) {this.storageSystem = storageSystem;this.policy = policy;}public void archiveData() {System.out.println("开始数据归档...");// 获取需要归档的数据List<DataRecord> dataToArchive = storageSystem.getDataToArchive(policy);if (dataToArchive.isEmpty()) {System.out.println("没有需要归档的数据");return;}// 归档数据for (DataRecord record : dataToArchive) {try {storageSystem.moveToArchive(record);System.out.println("数据已归档: " + record.getId());} catch (Exception e) {System.err.println("数据归档失败: " + record.getId() + ", 错误: " + e.getMessage());}}System.out.println("数据归档完成，共归档 " + dataToArchive.size() + " 条记录");}}// 存储系统public static class StorageSystem {private Map<String, DataRecord> hotStorage;private Map<String, DataRecord> coldStorage;private Map<String, DataRecord> archiveStorage;public StorageSystem() {this.hotStorage = new ConcurrentHashMap<>();this.coldStorage = new ConcurrentHashMap<>();this.archiveStorage = new ConcurrentHashMap<>();// 初始化一些测试数据initializeTestData();}private void initializeTestData() {// 创建一些测试数据for (int i = 1; i <= 1000; i++) {DataRecord record = new DataRecord("record-" + i, "数据内容 " + i, new Date(System.currentTimeMillis() - i * 24 * 60 * 60 * 1000L));if (i <= 100) {hotStorage.put(record.getId(), record);} else if (i <= 500) {coldStorage.put(record.getId(), record);} else {archiveStorage.put(record.getId(), record);}}}public List<DataRecord> getDataToArchive(DataArchivingPolicy policy) {List<DataRecord> toArchive = new ArrayList<>();// 根据策略获取需要归档的数据Date cutoffDate = new Date(System.currentTimeMillis() - policy.getArchiveThreshold());coldStorage.forEach((id, record) -> {if (record.getCreateTime().before(cutoffDate)) {toArchive.add(record);}});return toArchive;}public void moveToArchive(DataRecord record) {// 从冷存储中移除coldStorage.remove(record.getId());// 添加到归档存储archiveStorage.put(record.getId(), record);}public int getHotStorageSize() {return hotStorage.size();}public int getColdStorageSize() {return coldStorage.size();}public int getArchiveStorageSize() {return archiveStorage.size();}}// 数据记录public static class DataRecord {private String id;private String content;private Date createTime;public DataRecord(String id, String content, Date createTime) {this.id = id;this.content = content;this.createTime = createTime;}public String getId() { return id; }public String getContent() { return content; }public Date getCreateTime() { return createTime; }}// 数据归档策略public static class DataArchivingPolicy {private long archiveThreshold; // 归档阈值（毫秒）private int batchSize; // 批处理大小public DataArchivingPolicy(long archiveThreshold, int batchSize) {this.archiveThreshold = archiveThreshold;this.batchSize = batchSize;}public long getArchiveThreshold() {return archiveThreshold;}public int getBatchSize() {return batchSize;}}// 系统巡检服务public static class SystemInspectionService {private List<SystemInspector> inspectors;private NotificationService notificationService;public SystemInspectionService(NotificationService notificationService) {this.inspectors = new ArrayList<>();this.notificationService = notificationService;}public void registerInspector(SystemInspector inspector) {inspectors.add(inspector);}public InspectionReport performInspection() {System.out.println("开始系统巡检...");InspectionReport report = new InspectionReport();for (SystemInspector inspector : inspectors) {try {InspectionResult result = inspector.inspect();report.addResult(result);if (!result.isHealthy()) {notificationService.sendAlert(result.getMessage());}} catch (Exception e) {InspectionResult errorResult = new InspectionResult(inspector.getName(), false, "巡检失败: " + e.getMessage());report.addResult(errorResult);notificationService.sendAlert("系统巡检异常: " + e.getMessage());}}System.out.println("系统巡检完成");return report;}}// 系统巡检器接口public interface SystemInspector {String getName();InspectionResult inspect() throws Exception;}// CPU使用率巡检器public static class CpuUsageInspector implements SystemInspector {@Overridepublic String getName() {return "CPU使用率巡检器";}@Overridepublic InspectionResult inspect() throws Exception {// 模拟获取CPU使用率double cpuUsage = 50 + Math.random() * 40; // 50-90%if (cpuUsage > 80) {return new InspectionResult(getName(), false, "CPU使用率过高: " + String.format("%.2f", cpuUsage) + "%");}return new InspectionResult(getName(), true, "CPU使用率正常: " + String.format("%.2f", cpuUsage) + "%");}}// 内存使用率巡检器public static class MemoryUsageInspector implements SystemInspector {@Overridepublic String getName() {return "内存使用率巡检器";}@Overridepublic InspectionResult inspect() throws Exception {// 模拟获取内存使用率double memoryUsage = 40 + Math.random() * 50; // 40-90%if (memoryUsage > 85) {return new InspectionResult(getName(), false, "内存使用率过高: " + String.format("%.2f", memoryUsage) + "%");}return new InspectionResult(getName(), true, "内存使用率正常: " + String.format("%.2f", memoryUsage) + "%");}}// 磁盘空间巡检器public static class DiskSpaceInspector implements SystemInspector {@Overridepublic String getName() {return "磁盘空间巡检器";}@Overridepublic InspectionResult inspect() throws Exception {// 模拟获取磁盘使用率double diskUsage = 30 + Math.random() * 60; // 30-90%if (diskUsage > 85) {return new InspectionResult(getName(), false, "磁盘空间不足: " + String.format("%.2f", diskUsage) + "%");}return new InspectionResult(getName(), true, "磁盘空间正常: " + String.format("%.2f", diskUsage) + "%");}}// 巡检结果public static class InspectionResult {private String inspectorName;private boolean healthy;private String message;public InspectionResult(String inspectorName, boolean healthy, String message) {this.inspectorName = inspectorName;this.healthy = healthy;this.message = message;}public String getInspectorName() { return inspectorName; }public boolean isHealthy() { return healthy; }public String getMessage() { return message; }}// 巡检报告public static class InspectionReport {private List<InspectionResult> results;public InspectionReport() {this.results = new ArrayList<>();}public void addResult(InspectionResult result) {results.add(result);}public boolean isSystemHealthy() {return results.stream().allMatch(InspectionResult::isHealthy);}public String getSummary() {int healthyCount = (int) results.stream().filter(InspectionResult::isHealthy).count();int unhealthyCount = results.size() - healthyCount;return String.format("巡检完成: 共%d项检查, %d项正常, %d项异常", results.size(), healthyCount, unhealthyCount);}public List<InspectionResult> getUnhealthyResults() {return results.stream().filter(result -> !result.isHealthy()).collect(Collectors.toList());}}// 通知服务public static class NotificationService {private List<String> notifications;public NotificationService() {this.notifications = new CopyOnWriteArrayList<>();}public void sendAlert(String message) {String notification = "[ALERT] " + new Date() + ": " + message;notifications.add(notification);System.out.println(notification);}public void sendInfo(String message) {String notification = "[INFO] " + new Date() + ": " + message;notifications.add(notification);System.out.println(notification);}public List<String> getNotifications() {return notifications;}}// 可视化分析服务public static class VisualizationService {private SystemInspectionService inspectionService;public VisualizationService(SystemInspectionService inspectionService) {this.inspectionService = inspectionService;}public void generateDashboard() {InspectionReport report = inspectionService.performInspection();System.out.println("\n=== 系统状态仪表板 ===");System.out.println(report.getSummary());if (!report.isSystemHealthy()) {System.out.println("\n异常项目:");for (InspectionResult result : report.getUnhealthyResults()) {System.out.println("- " + result.getInspectorName() + ": " + result.getMessage());}}System.out.println("\n=== 系统资源使用情况 ===");System.out.println("- CPU使用率: " + (40 + Math.random() * 40) + "%");System.out.println("- 内存使用率: " + (30 + Math.random() * 50) + "%");System.out.println("- 磁盘使用率: " + (20 + Math.random() * 60) + "%");System.out.println("\n=== 存储使用情况 ===");System.out.println("- 热存储: " + (50 + Math.random() * 100) + "GB");System.out.println("- 冷存储: " + (200 + Math.random() * 300) + "GB");System.out.println("- 归档存储: " + (500 + Math.random() * 1000) + "GB");}}// 主方法 - 演示可运维系统public static void main(String[] args) throws Exception {// 创建通知服务NotificationService notificationService = new NotificationService();// 创建系统初始化和预热服务SystemInitializer systemInitializer = new SystemInitializer();SystemWarmer systemWarmer = new SystemWarmer();// 注册系统组件DatabaseComponent dbComponent = new DatabaseComponent("主数据库");CacheComponent cacheComponent = new CacheComponent("分布式缓存");systemInitializer.registerComponent(dbComponent);systemInitializer.registerComponent(cacheComponent);systemWarmer.registerComponent(dbComponent);systemWarmer.registerComponent(cacheComponent);// 初始化系统systemInitializer.initialize();// 预热系统systemWarmer.warmUp();// 创建存储系统和归档策略StorageSystem storageSystem = new StorageSystem();DataArchivingPolicy archivingPolicy = new DataArchivingPolicy(90L * 24 * 60 * 60 * 1000, // 90天1000 // 每批处理1000条记录);// 创建数据归档服务DataArchivingService archivingService = new DataArchivingService(storageSystem, archivingPolicy);// 执行数据归档archivingService.archiveData();// 创建系统巡检服务SystemInspectionService inspectionService = new SystemInspectionService(notificationService);// 注册巡检器inspectionService.registerInspector(new CpuUsageInspector());inspectionService.registerInspector(new MemoryUsageInspector());inspectionService.registerInspector(new DiskSpaceInspector());// 执行系统巡检InspectionReport report = inspectionService.performInspection();System.out.println("\n" + report.getSummary());// 创建可视化分析服务VisualizationService visualizationService = new VisualizationService(inspectionService);// 生成仪表板visualizationService.generateDashboard();// 显示通知System.out.println("\n=== 通知历史 ===");notificationService.getNotifications().forEach(System.out::println);// 关闭系统组件dbComponent.shutdown();cacheComponent.shutdown();}
}

11. 监控与报警：实时感知，快速响应

监控与报警是架构评审中保障系统稳定运行的最后一道防线。

  • 对系统内外部依赖的接口进行了全面监控，包括接口的响应时间、错误率等关键指标。
  • 在应用层面，暴露了丰富的系统内部指标，如线程池使用率、内存使用率等，为监控与报警提供了数据支持。
  • 针对系统层面使用的中间件与存储，也建立了完善的监控报警机制。
    例如，当数据库连接池使用率超过90%时，监控系统会立即发出报警，提醒运维人员及时采取措施，如增加数据库连接数或优化数据库查询。

通过这些监控报警设计，能够实时感知系统运行状态，快速响应异常情况，将故障影响降至最低。

架构示例图

自动化响应
报警系统
监控展示
数据处理
监控数据采集
自动化响应
脚本执行
自动修复
报警系统
实时报警
事件处理
通知渠道
监控展示
仪表板
图表
表格
数据处理
数据聚合
存储
监控采集器
应用指标
中间件指标
数据库指标
网络指标

架构示例代码

// 监控与报警系统实现
public class MonitoringAndAlertSystem {// 监控指标类型public enum MetricType {COUNTER,    // 计数器，只增不减GAUGE,      // 测量值，可增可减HISTOGRAM,  // 直方图，用于统计分布SUMMARY     // 摘要，用于统计分位数}// 监控指标public static class Metric {private String name;private String description;private MetricType type;private double value;private Map<String, String> labels;private long timestamp;public Metric(String name, String description, MetricType type) {this.name = name;this.description = description;this.type = type;this.value = 0;this.labels = new HashMap<>();this.timestamp = System.currentTimeMillis();}public void setValue(double value) {this.value = value;this.timestamp = System.currentTimeMillis();}public void increment(double delta) {this.value += delta;this.timestamp = System.currentTimeMillis();}public String getName() { return name; }public String getDescription() { return description; }public MetricType getType() { return type; }public double getValue() { return value; }public Map<String, String> getLabels() { return labels; }public long getTimestamp() { return timestamp; }public void addLabel(String key, String value) {labels.put(key, value);}}// 监控数据采集器public static class MetricCollector {private Map<String, Metric> metrics;public MetricCollector() {this.metrics = new ConcurrentHashMap<>();}public void registerMetric(Metric metric) {metrics.put(metric.getName(), metric);}public void recordMetric(String name, double value) {Metric metric = metrics.get(name);if (metric != null) {metric.setValue(value);}}public void incrementMetric(String name, double delta) {Metric metric = metrics.get(name);if (metric != null) {metric.increment(delta);}}public Metric getMetric(String name) {return metrics.get(name);}public List<Metric> getAllMetrics() {return new ArrayList<>(metrics.values());}}// 应用指标监控public static class ApplicationMetrics {private MetricCollector collector;public ApplicationMetrics(MetricCollector collector) {this.collector = collector;// 注册应用指标collector.registerMetric(new Metric("http_requests_total", "HTTP请求总数", MetricType.COUNTER));collector.registerMetric(new Metric("http_requests_duration_seconds", "HTTP请求耗时", MetricType.HISTOGRAM));collector.registerMetric(new Metric("jvm_memory_used_bytes", "JVM内存使用量", MetricType.GAUGE));collector.registerMetric(new Metric("jvm_thread_count", "JVM线程数", MetricType.GAUGE));collector.registerMetric(new Metric("app_errors_total", "应用错误总数", MetricType.COUNTER));}public void recordHttpRequest(String method, String path, int statusCode, double duration) {// 记录HTTP请求collector.incrementMetric("http_requests_total", 1);// 记录请求耗时Metric durationMetric = collector.getMetric("http_requests_duration_seconds");if (durationMetric != null) {durationMetric.increment(duration);}// 记录错误if (statusCode >= 400) {collector.incrementMetric("app_errors_total", 1);}}public void updateJvmMetrics(long memoryUsed, int threadCount) {// 更新JVM指标collector.recordMetric("jvm_memory_used_bytes", memoryUsed);collector.recordMetric("jvm_thread_count", threadCount);}}// 中间件指标监控public static class MiddlewareMetrics {private MetricCollector collector;public MiddlewareMetrics(MetricCollector collector) {this.collector = collector;// 注册中间件指标collector.registerMetric(new Metric("database_connections_active", "数据库活跃连接数", MetricType.GAUGE));collector.registerMetric(new Metric("database_connections_max", "数据库最大连接数", MetricType.GAUGE));collector.registerMetric(new Metric("cache_hits_total", "缓存命中总数", MetricType.COUNTER));collector.registerMetric(new Metric("cache_misses_total", "缓存未命中总数", MetricType.COUNTER));collector.registerMetric(new Metric("message_queue_size", "消息队列大小", MetricType.GAUGE));}public void updateDatabaseMetrics(int activeConnections, int maxConnections) {// 更新数据库指标collector.recordMetric("database_connections_active", activeConnections);collector.recordMetric("database_connections_max", maxConnections);}public void recordCacheHit() {collector.incrementMetric("cache_hits_total", 1);}public void recordCacheMiss() {collector.incrementMetric("cache_misses_total", 1);}public void updateMessageQueueSize(int size) {collector.recordMetric("message_queue_size", size);}}// 报警规则public static class AlertRule {private String name;private String metricName;private String operator;private double threshold;private String severity;private String message;public AlertRule(String name, String metricName, String operator, double threshold, String severity, String message) {this.name = name;this.metricName = metricName;this.operator = operator;this.threshold = threshold;this.severity = severity;this.message = message;}public boolean evaluate(Metric metric) {if (metric == null) {return false;}double value = metric.getValue();switch (operator) {case ">":return value > threshold;case ">=":return value >= threshold;case "<":return value < threshold;case "<=":return value <= threshold;case "==":return value == threshold;case "!=":return value != threshold;default:return false;}}public String getName() { return name; }public String getMetricName() { return metricName; }public String getOperator() { return operator; }public double getThreshold() { return threshold; }public String getSeverity() { return severity; }public String getMessage() { return message; }}// 报警系统public static class AlertSystem {private List<AlertRule> rules;private List<Alert> activeAlerts;private NotificationService notificationService;public AlertSystem(NotificationService notificationService) {this.rules = new ArrayList<>();this.activeAlerts = new ArrayList<>();this.notificationService = notificationService;}public void addRule(AlertRule rule) {rules.add(rule);}public void evaluateMetrics(List<Metric> metrics) {for (Metric metric : metrics) {for (AlertRule rule : rules) {if (rule.getMetricName().equals(metric.getName()) && rule.evaluate(metric)) {// 检查是否已有活跃的报警boolean existingAlert = activeAlerts.stream().anyMatch(alert -> alert.getRuleName().equals(rule.getName()));if (!existingAlert) {// 创建新报警Alert alert = new Alert(rule.getName(),rule.getSeverity(),rule.getMessage(),metric.getValue(),new Date());activeAlerts.add(alert);notificationService.sendAlert(alert);}}}}// 检查是否需要关闭报警checkAlertResolution();}private void checkAlertResolution() {Iterator<Alert> iterator = activeAlerts.iterator();while (iterator.hasNext()) {Alert alert = iterator.next();Metric metric = getMetricByName(alert.getRuleName());if (metric != null && !getRuleByName(alert.getRuleName()).evaluate(metric)) {// 报警已解决iterator.remove();notificationService.sendResolution(alert);}}}private Metric getMetricByName(String metricName) {// 简化实现，实际应该从MetricCollector获取return null;}private AlertRule getRuleByName(String ruleName) {return rules.stream().filter(rule -> rule.getName().equals(ruleName)).findFirst().orElse(null);}public List<Alert> getActiveAlerts() {return new ArrayList<>(activeAlerts);}}// 报警public static class Alert {private String ruleName;private String severity;private String message;private double value;private Date timestamp;public Alert(String ruleName, String severity, String message, double value, Date timestamp) {this.ruleName = ruleName;this.severity = severity;this.message = message;this.value = value;this.timestamp = timestamp;}public String getRuleName() { return ruleName; }public String getSeverity() { return severity; }public String getMessage() { return message; }public double getValue() { return value; }public Date getTimestamp() { return timestamp; }}// 通知服务public static class NotificationService {private List<String> notifications;public NotificationService() {this.notifications = new CopyOnWriteArrayList<>();}public void sendAlert(Alert alert) {String message = String.format("[%s] %s: %s (当前值: %.2f) - %s",alert.getSeverity(), alert.getRuleName(), alert.getMessage(), alert.getValue(), new Date());notifications.add(message);System.out.println("报警: " + message);// 这里可以添加实际的通知逻辑，如发送邮件、短信等}public void sendResolution(Alert alert) {String message = String.format("[RESOLVED] %s: 报警已解决 - %s",alert.getRuleName(), new Date());notifications.add(message);System.out.println("报警解决: " + message);}public List<String> getNotifications() {return notifications;}}// 自动化响应public static class AutomatedResponse {private AlertSystem alertSystem;private Map<String, ResponseAction> actions;public AutomatedResponse(AlertSystem alertSystem) {this.alertSystem = alertSystem;this.actions = new HashMap<>();// 注册响应动作actions.put("high_database_connections", new ScaleUpDatabaseAction());actions.put("high_memory_usage", new RestartServiceAction());actions.put("high_error_rate", new CircuitBreakerAction());}public void processAlerts() {List<Alert> alerts = alertSystem.getActiveAlerts();for (Alert alert : alerts) {ResponseAction action = actions.get(alert.getRuleName());if (action != null && alert.getSeverity().equals("CRITICAL")) {try {action.execute();System.out.println("执行自动化响应: " + action.getClass().getSimpleName());} catch (Exception e) {System.err.println("自动化响应执行失败: " + e.getMessage());}}}}}// 响应动作接口public interface ResponseAction {void execute() throws Exception;}// 数据库扩容动作public static class ScaleUpDatabaseAction implements ResponseAction {@Overridepublic void execute() throws Exception {System.out.println("执行数据库扩容...");Thread.sleep(2000); // 模拟扩容过程System.out.println("数据库扩容完成");}}// 服务重启动作public static class RestartServiceAction implements ResponseAction {@Overridepublic void execute() throws Exception {System.out.println("执行服务重启...");Thread.sleep(3000); // 模拟重启过程System.out.println("服务重启完成");}}// 熔断器动作public static class CircuitBreakerAction implements ResponseAction {@Overridepublic void execute() throws Exception {System.out.println("启用熔断器...");Thread.sleep(1000); // 模拟熔断器启用过程System.out.println("熔断器已启用");}}// 监控仪表板public static class MonitoringDashboard {private MetricCollector collector;private AlertSystem alertSystem;public MonitoringDashboard(MetricCollector collector, AlertSystem alertSystem) {this.collector = collector;this.alertSystem = alertSystem;}public void display() {System.out.println("\n=== 监控仪表板 ===");System.out.println("时间: " + new Date());// 显示关键指标System.out.println("\n关键指标:");for (Metric metric : collector.getAllMetrics()) {System.out.printf("%-30s: %.2f %s%n", metric.getName(), metric.getValue(), metric.getType());}// 显示活跃报警List<Alert> activeAlerts = alertSystem.getActiveAlerts();if (!activeAlerts.isEmpty()) {System.out.println("\n活跃报警:");for (Alert alert : activeAlerts) {System.out.printf("[%s] %s: %s (当前值: %.2f)%n", alert.getSeverity(), alert.getRuleName(), alert.getMessage(), alert.getValue());}} else {System.out.println("\n当前无活跃报警");}}}// 主方法 - 演示监控与报警系统public static void main(String[] args) throws InterruptedException {// 创建监控数据采集器MetricCollector collector = new MetricCollector();// 创建应用和中间件指标监控ApplicationMetrics appMetrics = new ApplicationMetrics(collector);Middleware middlewareMetrics = new MiddlewareMetrics(collector);// 创建通知服务NotificationService notificationService = new NotificationService();// 创建报警系统AlertSystem alertSystem = new AlertSystem(notificationService);// 添加报警规则alertSystem.addRule(new AlertRule("high_database_connections", "database_connections_active", ">=", 90, "CRITICAL", "数据库连接数过高"));alertSystem.addRule(new AlertRule("high_memory_usage", "jvm_memory_used_bytes", ">=", 0.9, "WARNING", "JVM内存使用率过高"));alertSystem.addRule(new AlertRule("high_error_rate", "app_errors_total", ">=", 100, "CRITICAL", "应用错误数过高"));// 创建自动化响应AutomatedResponse automatedResponse = new AutomatedResponse(alertSystem);// 创建监控仪表板MonitoringDashboard dashboard = new MonitoringDashboard(collector, alertSystem);// 模拟系统运行for (int i = 0; i < 20; i++) {// 模拟HTTP请求appMetrics.recordHttpRequest("GET", "/api/users", 200, 0.05);// 模拟数据库连接数变化int dbConnections = 50 + (int)(Math.random() * 50);middlewareMetrics.updateDatabaseMetrics(dbConnections, 100);// 模拟缓存命中if (Math.random() > 0.3) {middlewareMetrics.recordCacheHit();} else {middlewareMetrics.recordCacheMiss();}// 模拟JVM内存使用long memoryUsed = (long)(Runtime.getRuntime().totalMemory() * 0.6 + Math.random() * 0.3);int threadCount = Thread.activeCount();appMetrics.updateJvmMetrics(memoryUsed, threadCount);// 模拟错误if (i > 10 && Math.random() > 0.8) {appMetrics.recordHttpRequest("POST", "/api/orders", 500, 0.1);}// 每5秒显示一次仪表板if (i % 5 == 0) {dashboard.display();// 评估报警规则alertSystem.evaluateMetrics(collector.getAllMetrics());// 处理自动化响应automatedResponse.processAlerts();}Thread.sleep(1000);}// 最终状态dashboard.display();// 显示通知历史System.out.println("\n=== 通知历史 ===");notificationService.getNotifications().forEach(System.out::println);}
}

在这里插入图片描述

总结

架构评审是一个复杂而系统的过程，需要从多个维度全面考量。在实际项目中，应根据项目所处阶段与业务目标，合理权衡各维度的重要性，制定出最合适的架构方案。随着项目的发展，也可以借助公司中间件与容器的标准化，逐步将一些架构工作交由专业团队负责，让业务代码更加专注于业务逻辑的实现。

在项目初期，可以适当简化一些架构设计，但必须对关键问题有清晰的认识与规划，确保系统能够在未来的发展中持续满足业务需求，实现稳定、高效、可扩展的目标。
